• Model NO.：JC35
• Type：Skid Steer Loader
• Engine Model：390
• Overall Operating Height(mm)：3300
• Bucket Capacity(M3)：0.25
• Operating Load(Kg)：500
• Rated Power (Kw)：26
• Displacement (L)：1.812
• Max. Speed (Km/H)：8
• Tire(Track) Modei：8.5-15
• Dumping Height：2050mm
• Dumping Reach(mm)：790
• Transport Package：Nude,Container
• Specification：CE
• Trademark：SINOHENG
• Origin：China
• Production Capacity：500 Units Per Month

Model
Main technical parameterJC35AOverall operating height(mm)3300BHeight to bucket hinge pin(mm)2725CHeight to top of cab(mm)2000DHeight to bottom of level bucket(mm)2558EOverall length without bucket(mm)2300FOverall length with bucket(mm)2950GDumping angle at maximum height(°)40HDumping height(mm)2050IDumping reach(mm)790JRollback of bucket on ground(°)30KRollback of bucket at full height(°)104LWheelbase(mm)897MGround clearance(mm)140NAngle of departure(°)20OFront turning radius without bucket(mm)1098PFront turning radius(mm)1760QRear turning radius(mm)1296RRear axle to bumper(mm)964STread width, centerline to centerline(mm) 1080TWidth(mm)1350UBucket width(mm)1400
