• Model NO.：2LTLZ45E
• Automatic Grade：Semi-Automatic
• Product Capacity：40～400t,h
• Certification：ISO9001: 2000
• Condition：New
• Transport Package：Nude Package
• Specification：Paving width: 2500-4500mm
• Trademark：MAXIZM
• Origin：China
• HS Code：8479102100
• Production Capacity：1000pes,Year

Basic Info.

Model NO. 2LTLZ45E Automatic Grade Semi-Automatic Product Capacity 40～400t/h Certification ISO9001: 2000 Condition New Transport Package Nude Package Specification Paving width: 2500-4500mm Trademark MAXIZM Origin China HS Code 8479102100 Production Capacity 1000pes/Year

Product Description

xgma 2.5m paving thickness Asphalt concrete paver 2LTLZ45ETechnical Features

1. Applicable for the highway subgrade (WLT) and road surface paving;



2. Introduce in the oversea advanced technology, absorb and innovate the new products with compact structure and reliable quality;



3. The key parts such as engine, transmission, hydraulic pump, motor and control valve are imported, featuring advanced performance and reliable quality;



4. The hydraulic extending screed could be adjusted steplessly in the paving width. With fuel heating and automatic ignition, the electrical fuel washing device is convenient for the daily maintenance and reducing the labor strength;



5. Travelling system: the wheel paver adopts the patented  semiaxis drive mechanism; the crawler paver adopts the patented track travelling mechanism and track supporting wheel mechanism which can adjust the floatation and machine height to ensure the reliable operation on the uneven ground;



6. Feeder system: multiple-friction disc clutch and electrohydraulic control, mature technology, convenient operation and large conveying capacity;



7. Automatic leveling sensors: the machine is equipped with two longitudinal and one transverse automatic leveling probe, which reaches the demand of high-grade road smoothness.



8. Centralized lubricating system: the system presses the lubricant into all bearings with high temperature to improve the reliability of the machine

Performance Parameters

Description	unit	2LTLZ45E
Paving width	mm	2500-4500
Max. paving thickness	mm	250
Theoretical productivity	t/h	220
paving speed	m/min	3.01-8.97
Running speed	km/h	2.29-16.74
Drive system		mechanical
Machine weight	t	11
Engine model&power		Quan Diesel 4JR3AG7, 55kW
Track shoe width	mm	wheel type
Hopper capacity	t	10
Auto. Leveling unit		China made
Auger diameter	mm	340
Screed extension mode		hydraulic extension
Vibration amplitude	mm
Vibration impact times	nos/min
Screed vibration frequency	Hz	0-50
Screed heating mode		fuel heating, auto. ignition
Fuel tank volume	L	143
Hydraulic tank volume	L	110
Centralized lubrication		China made
Material level unit
