• Model NO.：R215vs
• Drive Type：Internal Combustion Drive
• Bucket Capacity：0.92cbm
• Size：Large-Scale
• Certification：CE, ISO9001: 2000
• Condition：New
• Rated Output Power：110kw,1950rpm
• Marketing Type：New Product 2020
• Operation Weight：20900kg
• Engine Model：D04frc-Taa
• Rated Speed(R/Min)：5.5
• Max.Digging Height：9730mm
• Max. Digging Radius(mm)：6060mm
• Max.Digging Depth：6800mm
• Rate Flow：125kn
• Main Pump：161kn
• Rated Speed：5.6,3.7km,H
• Transport Package：Nude
• Specification：,
• Origin：Shandong, China
• HS Code：8429521200
• Production Capacity：1000

Basic Info.

Model NO. R215vs Drive Type Internal Combustion Drive Bucket Capacity 0.92cbm Size Large-Scale Certification CE, ISO9001: 2000 Condition New Rated Output Power 110kw/1950rpm Marketing Type New Product 2020 Operation Weight 20900kg Engine Model D04frc-Taa Rated Speed(R/Min) 5.5 Max.Digging Height 9730mm Max. Digging Radius(mm) 6060mm Max.Digging Depth 6800mm Rate Flow 125kn Main Pump 161kn Rated Speed 5.6/3.7km/H Transport Package Nude Specification / Origin Shandong, China HS Code 8429521200 Production Capacity 1000

Product Description

Famous BrandEarhtmoving Machinery 14ton Crawler Excavator 150VS with High Qaulity
Product Overview

1.Best excavator for sale with High quality and competitive price.
2.Our excavator used has Humanized design more comfortable.
3.TOP excavator seller with Best after-sales.
4. Spare excavator parts for sale too.


Parameter

Specification:
Operation Weight: 20900kg
Bucket Capacity: 0.92m³
Engine Model: Hyun-dai D6BV-C
Engine Power: 110kw/1950rpm
Max torque: 58/1600kgf.m/rpm

Hydraulic system
Working pressure: 330Kgf/cm2
Max.flow: 2*222L/min

Performance
Travel Speed: 5.3/3.4km/hr
Swing Speed: 12rpm
Max.digging force(bucket): 14370kgf
Max.digging force(jib): 10240kgf
Max. Traction: 19500kgf
Grade Ability: 35degree
Operation Modth: CAPO computer-controlled, self-diagnostic system

Specification:
A-Crawler Length: 4160mm
B-track ground length: 3370mm
C-Stick length: 2200mm
D-Track shoe width: 600mm
E-Min.ground clearance: 480mm

Oil Tank: 400L
Hydraulic tank: 160L

Dimensions
F-Total length: 9530mm
G-Overall width: 2800mm
H- Total height: 3030mm
I- Counter weight ground clearance: 1060 mm
J- Tail length: 2770mm
K-Up width: 2740mm
L-Cabin Height: 2920mm
J- Tail radius of gyration: 2840mm

Operating range
A.Max. Digging distance: 9980mm
A'Max. Surface digging distance: 9820mm
B-Max. digging depth: 6730mm
B'-Max. Valid digging depth: 6560mm
C Max.vertical digging depth: 6280mm
D-Max. digging height: 9600mm
E-Max.dumping height: 6780mm
F-Minimum radius of gyration: 3740m

Photos


About Our Company
We are a top package equipment solution provider in Qingdao China, especially for construction machinery, heavy industrial equipment and vehicle. We represent our own Maxizm brand machinery and high quality China machinery brands such as We are a top package equipment solution provider in Qingdao China, especially for construction machinery, heavy industrial equipment and vehicle. We represent our own Maxizm brand machinery and high quality China machinery brands such as SANY, ZOOMLION,SEM, SDLG, SHANTUI, etc.
