• Model NO.：933E
• Drive Type：Internal Combustion Drive
• Bucket Capacity：>1.5m³
• Size：Large-Scale
• Certification：CE, ISO9001: 2000
• Condition：New
• Bucket Digging Force：187kn
• Transport Package：Roro,Container,Bulk
• Specification：32TON
• Trademark：SINOMADA
• Origin：China
• HS Code：84295100
• Production Capacity：100 Units, Month

Product DescriptionModel933E Stage II933E Stage IIIAOperating weight with cab31800-32900 kg31800-32900 kgEngine power160 kW (215 hp) @ 2200 rpm169 kW (227 hp/230 ps) @ 2050 rpmBucket capacity1.4 / 1.6 m³1.4 / 1.6 m³Maximum travel speed (High)5.5 km/h5.5 km/hMaximum travel speed (Low)3.0 km/h3.0 km/hMaximum swing speed10.3 rpm10.3 rpmArm breakout force137 kN137 kNArm breakout force Power boost149 kN149 kNBucket breakout force187 kN187 kNBucket breakout force Power boost203 kN203 kNShipping length10650 mm10650 mmShipping width3190 mm3190 mmShipping height3525 mm3525 mmTrack shoe width (std)600 mm600 mmBoom6200 mm6200 mmArm3050 mm3050 mmDigging reach10653 mm10653 mmDigging reach on ground10453 mm10453 mmDigging depth7300 mm7300 mmVertical wall digging depth6216 mm6216 mmCutting height10300 mm10300 mmDumping height7265 mm7265 mmMinimum front swing radius4040 mm4040 mmModel6C8.3QSB7EmissionEPA Tier 2 / EU Stage IIEPA Tier 3 / EU Stage IIIASystem maximum flow2×266 L/min (2x70 gal/min)2×266 L/min (2x70 gal/min)System pressure34.3 MPa34.3 MPa
