• Model NO.：JS 750
• Certification：ISO9001: 2000, CE
• Condition：New
• Color：White
• Demension：4970*3300*6520mm
• Transport Package：Standard Seaworthy Packing
• Specification：CE, ISO, SGS
• Trademark：QUNFENG
• Origin：China
• HS Code：8474809090
• Production Capacity：100 Set One Year

CHARACTERISTICS
TECHNICAL DATA:

Model		JS1000	JS1500	JS2000	JS3000	JS4000
Feeding Capacity		1600L	2400L	3000L	4800L	6000L
Exceeding Capacity		1000L	1500L	2000L	3000L	4000L
Productivity		50m3 /h	75m3 /h	≈120m3 /h	≈180m3 /h	≈240m3 /h
Maximum material diameter Oaggregate(pebble/crushed stone)		80/60mm	80/60mm	≤150mm	≤150mm	≤150mm
Mixing Vane	Rotate speed	25.5r/min	26r/min	≈24.3r/min	≈24.3r/min	≈24.3r/min
	Quantity	2×8	2×8	14	16	20
Mixing moto	Power	2×22kW	2×37kW	2×37kW	2×55kW	2×75kW
Lubrication oil pump	Power	0.05kW	0.05kW	0.09kW	0.09kW	0.09kW
Hydraulic oil pump	Power			2.2kW	2.2kW	2.2kW
Dimension	Working	8280×3150 ×7920mm	10540×3800 ×10140mm	3275×2320 ×2227mm	3771×2600 ×2225mm	4469×2600 ×2225mm
	Conveying	5500×2150 ×1800mm	7000×2300 ×2350mm
Weight		10000kg	13500kg	7500kg	9200kg	11800kg



Model		JS750	JS500
Feeding Capacity		1200L	800L
Exceeding Capacity		750L	500L
Productivity		≥35m3/h	≥25m3/h
Max.Diameter Of principal material		80/60mm	60/40mm
Mixing Vane	Rotate speed	30.5r/min	35r/min
	Quantity	2×7	2×7
Power		38.8kW	25.3kW
Dimension	Working	4970×3330×6520mm	5140×3000×5600mm
	Conveying	4500×2250×2470mm	3500×2260×2380mm
Weight		6800kg	4000kg

Any further information please contact our company .Or please visit oue website :qunfeng-machine.en.made-in-china.com


QUNFENG MACHINERY



Global service system

As a model enterprise of China building material machinery, Qunfeng provides upscale and high-quality machinery with intelligent technology for their customers. Covering six continents with 7 overseas service stations and 24 domestic offices, Qunfeng has served 8000 clients from 110 countries and regions with more efficient intelligent manufacturing equipment. Qunfeng has earned great reputation in the world with its products being exported to high-level market worldwide, include Asia, Europe, South America, Oceania, Africa and North America.
