2ton Mini Excavator for Sale
Shanghai Super-Above Industry Holdings Co., Ltd.- Type：Crawler Excavator
- Usage：Special Excavator
- Bucket：Grab Shovel
- Transmission：Hydraulic Transmission
- Drive Type：Electric Drive
- Bucket Capacity：0.04 Cubic Metre
Base Info
- Model NO.：mc
- Size：Large-Scale
- Certification：CE
- Condition：New
- Speed(F)：4.3,2.2 Km,H
- After-Sales Service Provided：Engineers Available
- Max Digging Radius：3900mm
- Warranty：1 Year
- Maximum Digging Height：3475mm
- Transport Package：Naked in Container
- Specification：CE
- Trademark：super-above
- Origin：Jiangsu, China
- HS Code：8474390000
- Production Capacity：10000PC,Year
Description
Operating weightKg 1795 Bucket capacity m³ 0.04 Engine Model / D782-E3B -CBH-1 Style Direct injection / √ Four strokes / √ Water cooling / √ Turbo-charging / × Air to air intercooler / / No. of cylinders / 3 Output power kw/rpm 9.8/2300 torque/speed N.m 44.5/1800 Displacement L 0.778 Travel speed(H/L) km/h 4.3/2.2 Main performance Rotating speed r/min 9.5 Gradeability ° 30° Ground pressure kPa 28.5 Bucket digging force kN 16 Arm crowd force kN 10 Maximum traction kN 15.6 Main pump / / Hydraulic system Rated flow of main pump L/min 56.8 Pressure of prime valve MPa 22 Pressure of travel system MPa 22 Pressure of swing system MPa 11 Pressure of pilot system MPa 3.9 Oil Capacity Fuel tank capacity L 18 Hydraulic tank capacity L 17 Engine oil capacity L 3.8 Overall length mm 3560 Appearance size Overall width mm 1240 Overall height mm 2348 Width of platform mm 990 Length of crawler mm Overall width of chassis mm 990/1240 Width of crawler mm 230 Track length on ground mm 1270 Crawler gauge mm 760/1010 Clearance under counterweight mm 450 Min. ground clearance mm 145 Min. tail swing radius mm 620 Height of track mm Max. digging height mm 3475 Working scope Max. dumping height mm 2415 Max. digging depth mm 2290 Max. vertical wall digging depth mm 1750 Max. digging reach mm 3900 Min. swing radius mm 1530 Standard Length of boom mm 1690 Worker Length of arm mm 1100 Bucket capacity m³ 0.04
FEATURES & APPLICATION
The widened track shoes guarantee low ground pressure, high stability, and powerful traction to fulfill precise horizontal operations.
The wet type steering clutch and brake can prolong the service life and are interlinked with each other toguarantee the rapid and flexible steering
controls by joysticks.
It can complete the digging, handling, and landfill operations of earthworks and is suitable for the engineeringconstructionsfor roads, farms, water
conservancy projects, municipal projects, and energy projects.
FEATURES & APPLICATION
The widened track shoes guarantee low ground pressure, high stability, and powerful traction to fulfill precise horizontal operations.
The wet type steering clutch and brake can prolong the service life and are interlinked with each other toguarantee the rapid and flexible steering
controls by joysticks.
It can complete the digging, handling, and landfill operations of earthworks and is suitable for the engineeringconstructionsfor roads, farms, water
conservancy projects, municipal projects, and energy projects.
