Construction Machinery Sg16-3 Road Machine Motor Grader
Acntruck Automobile Sales (Shanghai) Co., Ltd.- Certification：TUV, UL, ISO, RoHS, CE
- Condition：New
- Application：Railway, Mine, Farmland, Highway
- Transmission：Hydraulic - Mechanical
- Walking Mode：Wheeled
- Type：Small Grader
Base Info
- Model NO.：SG16-3
- Rated Power/Speed：118 Kw,2200 Rpm
- Displacement：5.9 L
- Maximum Torque/Speed：670 N.M,1500 Rpm
- Minimum Fuel Consumption：205 G,Kw.H
- Minimum Turning Radius：7800 mm
- Number of Cylinders：6
- Brake Pressure：10 MPa
- Operating Weight：15400 Kg
- Front Axle Load：4600kg
- Rear Axle Load：10800kg
- Transport Package：Nude Package
- Specification：8726*2600*3400mm
- Trademark：Shantui
- Origin：China
- Production Capacity：50 Unit Per Month
Description
Overview
Packaging & Shipping
