Hand Held Concrete Power Trowel with Honda/Robin/B&S Engine

Shanghai Super-Above Industry Holdings Co., Ltd.
  • Shotcrete Type：Wet
  • Machining Process：Hydraulic

Base Info

  • Model NO.：SACPTBS
  • Structure：Rotor Type
  • Productivity：180m²,h
  • Feeding Height：1370mm
  • Vibrating Amplitude：2.4mm
  • Certification：ISO9001: 2000, CE
  • Condition：New
  • Color：Orange
  • Engine Power(HP)：5.5-6.5
  • Running Speed Rpm/Min)：0-126rpm
  • Engine Type：Air-Cooled.Single Cylinder,4-Stroke
  • Blade Angle：0~15°
  • Working Diamete：1000mm
  • Operation Weight：95kg
  • Transport Package：Carton with Steel Frame
  • Specification：CE
  • Trademark：Super-above
  • Origin：Jiangsu, China
  • HS Code：84306100
  • Production Capacity：1000PC,Year

Description

internal combustion engine

Engine

HONDA GX160

HONDA GX160

Engine power

5.5HP

5.5HP

Diameter of the working table

800mm

900mm

Working speed

120-140r/min

120-140r/min

Size

1810*760*880mm

1910*930*1070mm

Weight

85kg

95kg

  Features

1. Over-built gearbox assures long service life
2. Heavy-weight design to assure a superior finish
3. Height adjustable handle, assures operator comfort and easy control
4. Lifting tube as standard feature allows trowel to be transported on the jo-site with only two people
5. Centric-safety switch, shuts the engine down in the event of the operator loosing control of the unit
6. Screw control ensures precise blade adjustment
7. Lifting hook (weight 2.5kg) is available as optional
8. Throttle control is available as optiona

A power trowel is used to create a level, smooth finish on a large, flat area of concrete, such as an interior floor, or a poured patio slab for a deck.
They use single or multiple blades that rotate in a safety cage. Use a pushable concrete power trowel or riding model based on the size of your job.
Blades measure from 24 to 46 inches long and come in three types: floating, finish and combined.
