• Model NO.：HW
• Certification：CE, ISO 9001:2008
• Condition：New
• Min Ground Interspace：380mm
• Main Valve Flow：100L,Min
• Drilling Diameter：130-800mm
• Climb Angle：35
• Rated Speed：2400r,Min
• Max Drill Depth：3600mm
• Max Travel Speed：5km,H
• Rated Power：55kw
• Weight：7200kg
• Transport Package：Wooden Case
• Specification：CE
• Trademark：HW
• Origin：Shangdong China
• HS Code：8430100000
• Production Capacity：50000set,Year

1Diesel engine power65kw2Walking motor torque (max)5700N.M3Rotary motor max torque(impact drill)2000-2500N.M4Rotary motor max torque(Auger drill)8000-10000N.M5Pile height (max)4500mm6Mast route3700mm7Drill depth(impact drill)3500mm8Drill diameters(impact drill)68-300mm9Drill depth(auger drill)3500mm10Drill diameters(auger drill)90-500mm11Drill angle(L/R)25/-90 °12Drill angle(forward/backward)20/-20 °13Hydraulic system pressure16Mpa14Hydraulic system flow90L/min15Travelling speed1.6Km/h16Chassis spec2500*2000*520mm17Track chassis height300mm18Track height above the ground230mm19Clambing ability:≤ 30°20Track working pressure13Mpa21Track rotation angle360°22Hydraulic hammer impact power6-8T23Dimension(L*W*H)4000*2000*6000mm (Working)24Dimension(L*W*H)6000*2000*2400mm (Folden)25Net weight6000kgs
