• Model NO.：320*100*38
• Links：38(Can Be Customized)
• Length：3800mm
• Warranty：12 Months Under Normal Use
• Color：Black
• Material：Rubber and Steel
• Weight：101.4kg
• Transport Package：Bare Packing or Wooden Pallet
• Specification：320*100*38
• Trademark：No Marks or As Buyer′s Requests
• Origin：Shanghai, China
• HS Code：8431499900
• Production Capacity：3000 Pieces,Month

Basic Info.

Model NO. 320*100*38 Links 38(Can Be Customized) Length 3800mm Warranty 12 Months Under Normal Use Color Black Material Rubber and Steel Weight 101.4kg Transport Package Bare Packing or Wooden Pallet Specification 320*100*38 Trademark No Marks or As Buyer′s Requests Origin Shanghai, China HS Code 8431499900 Production Capacity 3000 Pieces/Month

Product Description

The characteristics of rubber tracks

1. Rubber tracks cause less damage to roads than steel tracks, and less rutting on soft ground than steel tracks .

2. A benefit to equipment operating in congested areas, rubber tracks make less noise than steel tracks .

3. Rubber tracks permit machines to travel at a higher speed than steel tracks .

4. Rubber tracks insulated machine and operator from vibraion, extedin the service life of machine and decreasing operator's fatigue.

5. The ground pressure of rubbr tracks equipped machinery can be fairly low, about 0.14-2.30 kg/m2, a major reason for its use on wet and soft terrain.

6. The added traction of rubber tracked vehicles permits them to pull twice the load of wheeled vehicles of the same weight.

7. Rubber tracks' pulling performance being twice that of wheels, it permits the lighter vehicles equip with rubber track to do the same pulling work than that of wheeled vehicles.



The notices of using rubber tracks

1. Adjust the tension of the rubber crawler so that the height, the variable range is 10-20mm when the machine is lifted. Readjust when the tension decreases. (Be careful because the rubber crawler may come off if the tension is too low).

2. Avoid projection from the frame around the rubber crawler, especially on its inner circumference. (Rubber crawlers are easily deformed; If it comes into contact with the frame, an accident such the rubber being cut can occur).

3. Avoid sharp projections when traveling.

4. Avoid turning too fast on concrete roads with a high coefficient of frction because this can cause accidents such as cutting the rubber.

5. Be careful that no oil, etc adheres to the rubber track. If it does, wipe it off immediately.

6. When storing for long periods, keep indoors, away from direct sunshine and rain.

7. Replace as soon as possible when abrasion of sprockets is observed







Applicable machines	various kinds of dumpers
Material	rubber and steel
Specification	320*100*38
Installation position	Installed on the dumpers



Size	weigth/link		Size	Weight/link		Size	Weight/link
130*72	0.36		WD300*72	1.459		400*144	7.75
150*60	0.52		B300*84	2.88		400*144Y	7.41
150*72	0.55		T300*86	3.13		420*100	5.3
170*60	0.48		300*109KW	3.38		450*71	4.45
180*60	0.56		K300*109	3.56		DW450*71	4.82
180*72	0.64		300*109N	3.32		450*73.5	4.57
180*72K	0.87		300*109W	3.21		450*76	5.27
H180*72	0.77		320*52.5	1.69		450*81.5	5.24
190*60	0.59		320*54	1.81		450*81N	5.19
190*60	0.59		B320*84	2.95		450*81W	5.02
190*72	0.72		B320*86	2.99		450*83.5	5.47
200*72	0.84		B320*86SB	2.99		450*83.5Y	5.67
200*72K	1.07		B320*86C	3.01		450*84	4.22
230*48	0.87		B320*86Z	3.12		B450*86	4.33
230*48K	1.06		B320*86CM	3.01		B450*86SB	4.3
230*72	1.09		B320*86R	2.99		B450*86C	4.31
230*72K	1.34		T320*86	3.22		B450*86Z	4.51
230*96	1.77		T320*86MB	3.3		B450*86CM	4.37
230*101	1.92		T320*86SB	3.27		B450*86R	4.3
250*47	1.11		T320*86C	3.25		450*90	4.07
250*48.5	1.13		T320*86Z	3.53		KU450*90	3.9
250*52.5	1.04		320*90	2.85		450*110	6.9
250*52.5K	1.31		320*100	2.67		T450*100MB	5.3
250*72	1.17		320*100W	3.01		T450*100	5.09
B250*72	1.03		320*106	3.63		T450*100SB	5.16
250*96	2.21		350*52.5	1.85		T450*100C	5.2
250*109	2.39		350*54.5	2.31		T450*100Z	5.55
260*55.5	1.48		350*56	2.05		450*163	10.47
260*96	1.91		350*75.5	3.58		485*92W	7.62
260*109	2.16		350*90	1.85		500*71	7.5
280*72	1.43		350*100	3.69		500*90	5.38
280*106	3.05		350*108	3.92		500*92	7.81
300*52.5KB	1.67		350*109	4.12		500*92W	8.6
300*52.5KW	1.71		370*107	4.68		500*100	6.34
300*52.5N	1.44		400*72.5KB	3.44		500*146	9.97
300*52.5W	1.56		400*72.5KW	3.72		600*100	8.3
JD300*52.5N	1.54		400*72.5N	3.48		600*125	10.39
K300*52.5	1.72		400*72.5W	3.85		650*110	13.34
KB300*52.5N	1.55		400*72.5Y	3.62		650*120	13.75
300*53	1.81		400*74	3.4		650*125	15.8
300*55	1.88		400*75.5	4.09		700*100	10.9
300*55.5	1.95		400*86	4.14		700*125	14.29
300*71	3.31		400*90	2.22		750*150	21.34
300*72	1.77		400*107	4.95		800*125	19.14
			400*142	7.12		K800*150	21.55
ASV TRACK						M800*150	20.05
280*102*37	1.36		PAVER TRACK			900*150	31.23
380*102*42	1.9		356*152.4*46	4.81		1000*150	33.3
460*102*51	2.41		483*152.4*52	6.07
460*102*56	2.49		460*225*36	7.79		SPECIAL TRACK
460*102C*51	2.44					160*87.63*28	0.41
510*101.6*51	2.6					240*87.63*28	0.51
