• Vibrating Amplitude：1.6mm
• Certification：ISO9001: 2000, CE
• Condition：New
• Color：Red
• Concrete Slump Range：8~23cm
• Theoretical Pumping Times：24~27min
• Theoretical Output：150m3,H
• Reach Height：38m
• Emission Standard：Eruo III
• Max. Speed：85km,H
• Wheelbase：4600+1350mm
• Hopper Capacity：550L
• Distribution Valve：S Valve
• Hydraulic Oil Cooling：Wind Cooling
• Recommended Concrete Slump：12-23m
• Pipe Diameter：125mm
• Transport Package：Nude
• Specification：36350kg
• Origin：Hunan, China
• Production Capacity：100units,Week

 Max. Theor. output                       m³/h140/90Rated working pressure                      MPa35Pumping frequency                             min-127/17Hopper capacity                                   L550Filling height                                   mm1540Hydraulic system type opened loopDistribution valve S valveOil cylinder dia.×stroke                   mmφ130×2100Concrete cylinder    dia.×stroke            mmφ230×2100Hydraulic oil cooling Wind coolingRecommended concrete slump                    cm12~23Max. aggregate dimension                    mm40Boom  SectionStructure type 38X-5RZPlacing depth                               m38Max. horizontal distance                       m34Max. placing depth                          m24.9Slewing angle ±270°Boom number 5The length of boom section                      mm8890/8100/8105/5405/3500Sections folding angle 90°/180°/180°/250°/90°Pipe diameter                                mm125End hose length                            mm3000Min. height of opening placing boom        mm9610Outriggers span     (front×rear×side) mm6190×8345×7045Upper StructureUpper Structure Mass                  kg15260Dimensions(L×W×H)mm9845×2500×3596
