• Model NO.：Ycr180
• Certification：CE, ISO 9001:2008
• Condition：New
• Max. Output Torque：180kn.M
• Max. Drilling Diameter：1800mm
• Transport Package：Nude
• Specification：13695*3200*3460mm
• Trademark：TOP BRAND
• Origin：China
• HS Code：8427209000
• Production Capacity：100units,Month

Product Parameters

Project

Parameters

Chassis

Engine Type

C 6C8.3

Engine Power/Speed

194/1800

Crawler Expansion Width (From The Outside)

4100

Crawler Board Width

800

Traction Force

390

Power Head

Max. Output Torque

180

Power Head Speed

7-25

Max.Pull-Down Piston Push

`120

Max.Pull-Down Piston Pull

180

Pressure Oil Cylinder Stroke

3600

Winch

Main Winch

Max.Line Pull of the first layer

180

Max.Line Speed

46

Wire Rope Diameter

Φ26

Auxiliary Winch

Max.Line Pull of the first layer

50

Max.Line Speed

70

Wire Rope Diameter

Φ16

Mast

Mast Forward Inclination

5

Mast Sideward Inclination

±4

Hydraulic Pump

Max. Working Pressure

35

Depth and Diameter

Max. Drilling Diameter

1800

Max. Drilling Depth

55(60)

Drilling Pipe

Drilling Pipe

Φ406(440)

Working State Quality

62
