• Model NO.：Dh16-K2
• Condition：New
• Color：Yellow
• Rated Power/Rated Speed (Kw/Rpm)：142,2100
• Ripping Depth (mm)：492
• Operating Weight：17635kg
• Transport Package：Roro
• Specification：5800*3400*3180 mm
• Trademark：shantui
• Origin：Shandong, China
• Production Capacity：1000 Pieces,Per Month

Basic Info.

Model NO. Dh16-K2 Condition New Color Yellow Rated Power/Rated Speed (Kw/Rpm) 142/2100 Ripping Depth (mm) 492 Operating Weight 17635kg Transport Package Roro Specification 5800*3400*3180 mm Trademark shantui Origin Shandong, China Production Capacity 1000 Pieces/Per Month

Product Description

Shantui 160HP Dh16-K2 Hydrostatic Bulldozer, EPA Tier 4 Final/EU Stage 4 Emission
 High value and lower machine cost.
The K series crawler dozer is the latest generation hydrostatic-drive dozer from SHANTUI. Built off the the superiorities of the J series dozer, while using EPA Tier 4f/EU Stage IV engines, state-of-art technologies such as adjustable work-mode and grade assist, the new K series dozer becomes more powerful and intelligent, give you more productivity with less fuel consumption. K series dozer can be used in landscape, municipal engineering, earth-moving, grading, logging and many other applications.

[Product Parameter]

Parameter name	DH16-K2 XL (Extended version)
Performance parameters
Operating weight (Kg)	17635kg/38879lb (With traction frame)
Ground pressure (kPa)	50 (With 560mm track shoes)/45.9 (With 610mm track shoes)
Engine
Engine model	N67
Rated power/rated speed (kW/rpm)	142/2100
Overall dimensions
Overall dimensions of machine (mm)	5800*3400*3180
Driving performance
Forward speed (km/h)	0-10
Reversing speed (km/h)	0-10
Chassis System
Center distance of track (mm)	2040
Width of track shoes (mm)	560/610
Ground length(mm)	3075
Tank capacity
Fuel tank (L)	389
Working device
Blade type	PAT
Digging depth (mm)	675
Ripper type	Three-tooth ripper
Ripping depth (mm)	492

[Product Strengths]

Power System
1. The installed N67 electronic control engine conforms to the EPA Tier4 final/EU Stagei IV  emission regulation, featuring stronger power and higher energy-saving and environmental-friendliness. The after-treatment system adopts HI-eSCR technology, requiring no external EGR. The 600h oil maintenance interval reduces the maintenance costs.
2. The Shantui's innovative hydrostatic drive optimization technology is applied to achieve higher efficiency and energy-saving. The multiple operating modes are at the user's choice depending on the load of actual working condition to realize the reasonable match among power, efficiency, and energy consumption.

Standard mode - It can provide strong power performance and excellent operating control performance for the operator.

Power mode - It can provide stronger power performance to meet your higher needs for heavy-load condition.

Control system
1. The double-module (Function and safety) controller architecture verifies with each other to achieve higher safety and reliability.

2. The multiple functions, including multiple steering modes, hydraulic oil low temperature control, automatic low idling, fan reversing, and seat safety switch, are provided to achieve higher intelligence, higher efficiency, and higher safety of the machine.

3. The malfunction self-diagnosis function is provided to accurately indicate the malfunction cause and orientation and shorten the downtime.

4. The service software with distinct access hierarchy features high simpleness and practicability and easy learning and understanding.

5. The GPS automatic leveling systems, including Trimble, Topcon, Leica, and Moba, can be installed to meet the user needs under precision leveling condition and improve the efficiency.

Driving/Riding Environment
1. The standard A/C and heating system, the intelligent display and control terminal with integrated instruments, cigarette lighter, USB charging port, radio, and fire extinguisher are installed to provide more abundant personalized driving/riding experience.

2. The integrated large color LCD display and control terminal integrates the instruments to ensure easy and simple understanding, the multiple languages are provided for you to understand the system status at any time, and the multiple mode settings are provided, featuring high intelligence and convenience.

3. The optional reversing camera system can display the vision behind the vehicle to ensure the reversing safety.

4. The safety passageway system and the reasonably arranged safety handrails and anti-skid footplates for whole vehicle guarantee the driver's safety.
