• Model NO.：SWEA220LB
• Bucket Capacity：0.1~0.5m³
• Size：Large-Scale
• Certification：CE, ISO9001: 2000, ISO14001
• Condition：New
• Max. Cutting Height：12190mm
• Max. Dumping Height：9800mm
• Max. Digging Depth：11600mm
• Max. Reach：15100mm
• Hydraulic Spud：Optional
• Transport Package：Nude
• Specification：40 ton
• Trademark：SINOWAY
• Origin：China
• HS Code：84294990
• Production Capacity：100 Pics, Year

Engine ModelIsuzu/CumminsTypeSix-cylinder,water-cooled
turbocharged,mechanical injectionRated power106KWMain Technical Specification Operating weight40000KgStandard bucket capacity0.6m3Slewing speed13rpmStick digging force50.0KNBucket digging force64.0KNMain Features Tracked pontoon structure Big torque travelling device Big circular arc structure High capacity of fuel tank Main Applications River/Beach earth moving Swamp works Dredging applications Delta works Waterway deepening Hydraulic System Main pumpKAWASAKIMain valveKAWASAKIMotorKAWASAKIHydraulic flow rate2x210L/minHydraulic pressure32MPaTravelling System Travelling speed0~4.88km/hGrade ability58%Ground pressure0.013MPaNo. of chains300%Dimensions Overall length14500mmOverall width6100mmOverall height3950mmGround clearance1192mmLength of pontoon10200mmWidth of pontoon1760mmHeight of pontoon1700mmOptional Wide bucket Operating Scope Stick length5200mmA: Max. cutting height12190mmB: Max. dumping height9800mmC: Max. digging depth11600mmD: Max. reach15100mmWhy Choose Us
