Self-Loading Concrete Mixer with Diesel Engine
Shanghai Super-Above Industry Holdings Co., Ltd.- Shotcrete Type：Wet
- Machining Process：Hydraulic
Base Info
- Model NO.：SACM6
- Structure：Rotor Type
- Productivity：25m²,h
- Feeding Height：1370mm
- Vibrating Amplitude：2.0mm
- Certification：ISO9001: 2000, CE
- Condition：New
- Color：Blue
- Motor：Diesel,Gasoline,Electric
- Charging Capacity：350L,500L
- Discharge Way：Self-Loading
- Working Cycle Period：1min
- Towing：Two-Towing Wheels
- Hopper Model：Hydraulic Tipping Hopper
- Speed of Mixing Drum：20km,H
- Dragging：2 Tyres , 4 Tyres
- Water Supply Mode：Water Pump
- Transport Package：Naked in Container
- Specification：CE
- Trademark：Super-above
- Origin：Jiangsu, China
- HS Code：847431000
- Production Capacity：1000PC,Month
Description
Model
SACM(Wire rope hoisting tipping hopper)
Discharging volume
350L
Charging volume
560L
Water tank volume
110L
Capacity
10~14m3/h
Power source
Diesel engine, single-cylinder, water-cooled with battery starter
Power
11kw
Drum rotating-speed
13r/min
Max. dragging speed
20km/h
Dragging
2 tires
Total weight
1850kg
Dimension
3100x2320x3070mm
Power source: diesel engine. So it can also be used in areas without electricity supply.
More models of PARAMETERS
ModelSACM350 SACM500 Feeding capacity 560L 800L Discharge capacity 350L 500L Productivity 12-13m3/h 17-18m3/h Operation cycles 40times/h, (90s) 40times/h, (90s) Diesel engine YANMAR or Chinese brand YANMAR or Chinese brand Power 11.3KW 18kw Starting Manuel and key starting Manuel and key starting Drum speed 16r/m 16r/m Water tank volume 110L Customized Aggregate Diameter ≤60mm ≤60mm Tire Size 6.50-16 or customized 7.50-16 or customized Operation dimensions 4050*2150*2950mm 5200*2250*2950mm Delivery dimensions 1950*2080*2100mm 3500*2100*2250mm 20ft container 3pcs can not load 40gp container 6pcs 3pcs Weight 2050kgs 3500kgs
