• Model NO.：Clg 835
• Condition：New
• Color：Yellow
• Dimension：6760*2500*3300
• Overall Weight：10900kg
• Rated Bucket Capacity：1.7m 3
• Tipping Load：8300kg
• Max.Traction：100kn
• Max.Drawingforce：130kn
• Total Time of Three Devices：10.5s
• Engine：Yuchai Yc6108g
• Model Number：Liugon Clg 835
• Warranty：1 Year
• Transport Package：Nude
• Specification：CE
• Trademark：XCMG
• Origin：Jaingsu China
• HS Code：84295100
• Production Capacity：50, 000PCS,Year

Basic Info.

Model NO. Clg 835 Condition New Color Yellow Dimension 6760*2500*3300 Overall Weight 10900kg Rated Bucket Capacity 1.7m 3 Tipping Load 8300kg Max.Traction 100kn Max.Drawingforce 130kn Total Time of Three Devices 10.5s Engine Yuchai Yc6108g Model Number Liugon Clg 835 Warranty 1 Year Transport Package Nude Specification CE Trademark XCMG Origin Jaingsu China HS Code 84295100 Production Capacity 50, 000PCS/Year

Product Description

Product Description
Liugong Clg 835 small 3 Tons Wheel Loader with CE

1. Good quality with workable price;
2. Good-sales service with complete type;
3. Enjoy a good fame for advanced techniques
If you have interest in our dump loaders, please feel free to contact with us.

Engine Model	Yuchai YC6108G
Rated power	92KW
Bucket capacity	1. 7  M3
Rated load	3000kg
Operating weight	10900kg
Dump height	2911mm
Max. Digging force	93.5KN
Max. Traction force	100KN
Min. Operating radius (outside bucket)	5676mm
Min. Operating radius (outside the machine)	5140mm
Hydraulic torque converter	Double turbine
Tune pressure with hydraulic system safety valve	16Mpa
Steering Angle (Left/Right)	40 degree
Fuel tank capacity	150L
Cooling system	35L
Crankcase of diesel engine	15L
Torque converter & gear box system	45L
Main transmission (front axle/rear axle)	18L/18L
Hydraulic system capacity	150L
Tires	17.5-25
Dimension(mm) L*W*H	6760*2500*3300
Transmission	Planetary type,clutch with multiple disc,full power shift,force
Service brakes	Capliper discs,air hydraulic actuated on all four wheel
Parking brakes	Shoe-brake applies by manunlly control
Emergency brakes	Using parking brake,the brake will automatically /manually apply.Equipped with braking low-pressure
Fuel Tank	150L
Hydraulic tank	150L
Crankcase	15L
Transmission	45L
Different&final drivers-front	18L
Different&final drivers-rear	18L
