Powerful Lovol Evangel 6 Ton Mini Crawler Excavator Fr60e Price for Sale
Evangel Industrial (Shanghai) Co., Ltd.- Type：Crawler Excavator
- Usage：Special Excavator, Marine Excavator, Mining Excavator, GM Excavator
- Bucket：Shovel
- Transmission：Hydraulic Transmission
- Drive Type：Internal Combustion Drive
- Bucket Capacity：0.1~0.5m³
Base Info
- Model NO.：FR60E
- Size：Small-Scale
- Certification：CE, ISO9001: 2000
- Condition：New
- Transport Package：Nude Package
- Trademark：xcmg
- Origin：China
Description
Technical parameters
| Operation Weight (Standard Configuration) (kg) | 5730 |
|---|---|
| Standard Bucket Capacity ( m3) | 0.18 |
| Rated Power/Rotate Speed (KW/rpm) | 36.2/2100 |
| Transport Dimensions(mm) | 6090*1950*2660 |
| Bucket Breakout Force (KN) | 42 |
| Stick Breakout Force (KN) | 31 |
| Maximum Traction (KN) | 50.5 |
| Device | |
| High-low Speed (Km/h) | 4.2/2.5 |
| Climbing Performance(°) | 35 |
| Total Length of the Crawler | 2550 |
| Tail Turning Radius (mm) | 1700 |
| Width of the Crawler | 400 |
| Ground Pressure (Kpa) | 32.33 |
| Turning Mechanism | |
| Turning Speed (rpm) | 10.2 |
| Engine | |
| Model | Y ANMAR 4TNV94L |
| Type | Four Cylinders, Direct Injection, Naturally Aspirated, Water-cooling |
| Rated Torque/Rotate Speed (N.m/rpm) | 198/1400 |
| Cylinder Diameter*Stroke (mm) | 94*110 |
| Output Value (L) | 3.054 |
| Fuel Consumption (g/KW.h) | 247 |
| Fuel Tank Capacity (L) | 120 |
| Hydraulic System | |
| Main Pump Pressure (Mpa) | 24.5 |
| Main Pump Flow | 135*2 |
| Operating Scope | |
| Maximum Digging Height (mm) | 5170 |
| Maximum Dumping Height (mm) | 3500 |
| Maximum Digging Depth (mm) | 3925 |
| Maximum Digging Radius (mm) | 6110 |
