Heavy Equipment Roller Machine Construction Mini Pneumatic Roller for Road Paving

Sinoway Industrial (Shanghai) Co., Ltd.
  • Warranty:One Year
  • Type:Road Roller

Base Info

  • Model NO.:SWP1016H
  • Working Method:Wheeled
  • Axle:Biaxial Dual-Drum
  • Grinding Wheel Type:Light Grind
  • Compaction Depth:30cm
  • Engine Type:Diesel Engine
  • Travel Speed:40cm,s
  • Centrifugal Force:None
  • Certification:CE, ISO 9001:2008, ISO14001
  • Condition:New
  • Tire Number:F4+R5
  • Tire Size:11.00-20
  • Compaction Width:2286 mm
  • Fuel Tank:220 L
  • Engine Power:100 HP
  • Engine:Cummins
  • Transmission:Hydraulic
  • A/C:Standard
  • Weight:10-16 Ton
  • Transport Package:Nude
  • Specification:ISO
  • Trademark:SINOWAY
  • Origin:China
  • HS Code:84314990
  • Production Capacity:200 Unit Per Year
  • Package size per unit product:498.00cm * 225.00cm * 335.00cm
  • Gross weight per unit product:10000.000kg

Description

EngineModelCummins 4BT3.9 TypeFour-cylinder,water-cooled turbocharged,mechanical injectionRated power75kwRated speed2200rpmTransmissionTypeMechanical drive (Gear box)Grade ability20%Gear shifts(Forward/Reverse)F3/R2Travelling speed (km/h) Forward/Reverse I6.0/4.5Forward/Reverse II14.0/10.9Forward III16.0Axle and TyreType of main reducer Spiral bevel gear Gear ratio 1:6.17Final reducer Chain driven Chain gear ratio 1:2.17Single tire load (F/R)1778kgTyre number (F+R)4+5Tyre size 11.00-20Main Technical SpecificationMax. operating weight16000KgMin. operating weight 10000kgAverage ground pressure0.15 - 0.3MPaTyre pressure 0.2 - 0.8MPaCompacting width2286mmVertical oscillation ± 100mmSteering SystemType Hydraulic steering Working pressure13MPaSteering cylinder 90 x 50 x 260mmMin. steering radius 7500mmBraking System Service brake Air-over-hydraulic disc brake Parking brake Hand operated drum brake Service Capacities Hydraulic tank 67LGear box 10LFuel tank 220LEngine crank case 16LDimensionsOverall length4980mmOverall width 2286mmOverall height 3220mmWheelbase 3700mmGround clearance 300mm
