Engineering & Construction Machinery

Home > Product > Bulldozer

China Hbxg 13 Ton 3.1m3 Capacity Mini Crawler Bulldozer (SD5K)

Sinomada Heavy Industry (Changsha) Co., Ltd.
  • After-sales Service：1 Year
  • Warranty：1 Year
  • Type：Universal Type
  • Transmission：Hydraulic Transmission
  • Walking Mode：Crawler
  • Load and Unload Method：Front Discharge

Base Info

  • Model NO.：SD5K
  • Engine Power：74~147kw
  • Certification：CE, ISO9001: 2000
  • Condition：New
  • Color：Yellow
  • Operating Weight：13100kg
  • Transport Package：Roro,Container
  • Specification：130 Hp
  • Trademark：HBXG
  • Origin：China
  • HS Code：8429119000
  • Production Capacity：100unit,Month

Description

Overview Product Description

Product Parameters



ModelSD5K(130HP)Rated revolution(rpm)2200DozerPower-Angle-Tilting bladeRated power(kw)97Operation weight(kg)13100Max.torque(N.m/rpm)570/1450Ground pressure(kpa)45Rated fuel consumption(g/kw.h)190Track gauge(mm)1790Undercarriage systemtrack-type hydrostatic bulldozer with semi-rigid suspendedMin.ground clearance(mm)315Number of track rollers(each side)7Gradient30°/25°Number of carrier rollers(each side)2Dozing capacity(m³ )3.1Pitch(mm)190Blade width(mm)3060Width of shoe(mm)510Max.digging depth(mm)460Gear Overall dimensions(mm)4922×3060×2999Forward km/h0-10.5Engine TypeWEICHAI WP6G125E332Backward km/h.0-10.5 Detailed Photos
