• Certification：CE, ISO9001: 2000
• Condition：New
• Model：Mini Excavator Xe15
• Engine：3tnv82A
• Rated Output Power：16.5,2200kw,Rpm
• Standard Bucket Capacity：0.044m³
• Track Width：400mm
• Operating Weight：1640kg
• Ground Pressure：23.8kpa
• Crawer Width：230mm
• Crawer Gauge：850mm
• Dozer Black(Width/Height)：1080×225mm
• Transport Package：Suitable Package for Shipment
• Specification：CE
• Trademark：EVANGEL
• Origin：Jiangsu, China
• HS Code：84295212
• Production Capacity：30 Sets Per Month

Model XE15Operating weightkg1640Standard bucket capacitym³0.044EngineEngine Model/3TNV82ADirect injection/√Four strokes/√Water cooling/√Turbo charged/×Air to air intercooler/×No. of cylinders/3Rated power/speedkw/rpm16.5/2200Max. torque/speedN.m86.5/1320DisplacementL1.33performanceTravel speedkm/h4.4/2.4Swing speedr/min11Max. gradeability/30°Ground pressurekPa23.8Max.Bucket digging force kN13.9Max.arm crowd force kN8.8hydraulic systemMain pump/NACHI (Japan)Rate flow of main pumpL/min2×19.8+14.1Max pressure of prime relief valveMPa24Max pressure of travel systemMPa21Max pressure of swing systemMPa18Max pressure of pilot systemMPa3.3Oil capacityFuel tank capacityL20Hydraulic tank capacityL29Engine lubricationL5.5Overall dimensionA Overall lengthmm3760B Overall widthmm1080C Overall heightmm2400D Overall width of upperstructuremm1080E Track lengthmm1578F Overall width of undercarriagemm1080G crawer widthmm230H Dozer black(width/height)mm1080×225I Tumbler distancemm1217J Crawer gaugemm850K Clearance under counter weightmm472L Ground clearancemm180M Min.tail swing radiusmm1190operating rangeA Max. digging heightmm3615B Max. dumping heightmm2480C Max. digging depthmm2320E Max. vertical wall digging depthmm1520F Max. digging reachmm3915G Min. swing radiusmm1675H Max.dozer lifting heightmm220I Max.dozer cutting depthmm240 Angle of arm deflection Degree70/50

Welcome to contact me!




Evangel Industrial (Shanghai) Co., Ltd.
Evangel International Machinery Ltd.
Add: Suite 1326, Fortune Times Tower, No. 1438 North Shanxi Road, Shanghai, China


Web: evangelchina.en.made-in-china.com
Web: evangelchina.en.made-in-china.com
Alibaba: http://evangelchina.en.made-in-china.com
Made-In-China: http://evangelchina.en.made-in-china.com
 evangelchina.en.made-in-china.com

Feature:  China new excavator price/mini diggers/excavator

1.The compact excavator has a full open hood, which makes it easy to be repaired and maintenance,saving maintenance time and improves work efficiency.

2.The centralized lubrication is a facilitating for lubracating the slewing bearing and the internal tooth surface of the slewing motor.

3.The hyhdraulic oil level gauge,fuel level gauge,coolant reserve tank,window glass washing liquid tank are arranged in outer lower position for easy observation and to add.
