• Model NO.：SWEA220
• Drive Type：Internal Combustion Drive
• Bucket Capacity：0.5~1.0m³
• Size：Medium-Sized
• Certification：CE, ISO9001: 2000, ISO14001
• Condition：New
• Pontoon Size：9.5 Meters
• Spud Pile Length：4~10 Meters
• Pontoon Material：Alloy Steel
• Side Pontoon：Optional
• Hydraulic Piles：Optional
• Manhole：Optional
• Bolted Track Cleats：Standard
• Hydraulic System：Doosan
• Drive Chains：Three Strands
• 15m Long Reach：Optional
• Weight：30 Ton
• Transport Package：Nude
• Specification：ISO
• Trademark：SINOWAY
• Origin：China
• HS Code：84163600
• Production Capacity：100 PCS Per Year

Engine ModelCummins/IsuzuTypeSix-cylinder,water-cooled turbocharged,mechanical injectionRated power125KWRated speed2100rpmMain Technical Specification Operating weight42000KgStandard bucket capacity1.1m³Slewing speed 11rpm11rpmStick digging force110KNBucket digging force150KNMain Features Tracked pontoon structure Big torque travelling device Big circular arc structure High capacity of fuel tank Main Applications River/Beach earth moving Swamp works Dredging applications Delta works Waterway deepening Hydraulic System Main pumpKAWASAKIMain valveKAWASAKIMotorKAWASAKIHydraulic flow rate2x235L/minHydraulic pressure32MPaTravelling System Travelling speed0~5.4km/hGrade ability65%Ground pressure0.0135MPaNo. of chains3Dimensions Overall length12100mmOverall width6000mmOverall height3900mmGround clearance1192mmLength of pontoon10200mmWidth of pontoon1760mmHeight of pontoon1700mmOperating Scope Stick length3000mmA: Max. cutting height10980mmB: Max. dumping height8140mmC: Max. digging depth6940mmD: Max. reach10290mm
