Earthmoving Machine 21 Ton Wheel Excavator for Sale (XE210WB)
Sinomada Heavy Industry (Changsha) Co., Ltd.- Type：Wheel Excavator
- Usage：Special Excavator, Marine Excavator, Mining Excavator, GM Excavator
- Bucket：Shovel
- Transmission：Hydraulic Transmission
- Drive Type：Internal Combustion Drive
- Bucket Capacity：0.5~1.0m³
Base Info
- Model NO.：XE210WB
- Size：Medium-Sized
- Certification：CE, ISO9001: 2000
- Condition：New
- Product Type：Wheel Excavator
- Rated Power：129kw
- Max. Digging Depth：10582mm
- Max. Digging Height：9613mm
- Max. Digging Reach：5755mm
- Transport Package：Nude
- Specification：21140kg
- Origin：China
- HS Code：8429521200
- Production Capacity：100units,Month
Description
Overview
Product DescriptionModel Unit Parameter Operation weight kg 21140 Bucket capacity m³ 0.86 Engine Model / QSB6.7 Rated power kw/rpm 129/2200 Max.torque N.m 799 Displacement L 6.7 Fuel tank L 305 Main performance Rated flow L/min 220 Working pressure Mpa 32 Hydraulic tank L 202 Rotating speed r/min 13 Bucket digging force kN 115 Arm crowd force kN 91 Min.swing radius mm 6500 Travel speed km/h 9.5/31 Grade ability ° 35° Hydraulic system /Pump/Pilot pump / Tow ram pumps Apperance size AOverall length mm 9135 BOverall width mm 2552 COverall height mm 3370 DGround clearance of counterweight mm 1250 EMin.ground clearance mm 340 FTail swing radius mm 2820 GWheel base of crawler mm 2850 HTumbler distance mm 1890 Iwidth of chassis mm 2495 JDistance bttween the front axle and center rotation mm 1550 KHeight of engine hood mm 2542 LMax.dozer cutting depth mm 145 MMax.dozer lifting height mm 479 (/)Dozer(width/height) mm 2467/566 Working scope AMax.digging radius mm 9613 BMax.ground digging distance mm 9380 CMax.digging height mm 10528 DMax.dumping height mm 7530 EMax.digging depth mm 5755 F8Digging depth at the range of level 8 feets mm 5580 Standard configuration Length of bucket arm mm 2910 Bucket capacity m³ 0.86
Product Parameters
