Small Motor Grader 215HP Gh215 Motor Grader Parts

Oriemac Machinery & Equipment (Shanghai) Co., Ltd.
  • Colour：Optional
  • Engine Model：6CTA8.3
  • Rated Power/Speed：160kw,2200rpm
  • Dimension(Lxwxh)：9105×2625×3470mm
  • Operating Weight(Standard)：16500kg
  • Working Hydraulic Pressure：16 MPa

Base Info

  • Model NO.：GH215
  • Transmission Pressure：1.3~1.8MPa
  • Maximum Lift Above Ground：450mm
  • Basic Specification Engine Modelt6CTA8：500mm
  • Circle Reversing Rotation：360
  • Transport Package：Nude Package
  • Specification：CE, ISO
  • Trademark：XC
  • Origin：Jiangsu China
  • Production Capacity：3000,Month

Description


Basic specificationEngine model6CTA8.3Rated power/speed  160kW/2200rpmDimension(LxWxH)9105×2625×3470mmOperating weight(Standard)16500kg
Performance specification
Travelling speed ,forward5,8,11,16,26,38 km/hTravelling speed ,reverse5,8,11,16,26,38 km/hTractive force(f=0.75)98KNMax. gradeability20%Tire inflation pressure260 kPaWorking hydraulic pressure16 MPaTransmission pressure1.3~1.8MPa
Operating specification
Max. steering angle of front wheels±50°Max. lean angle of front wheels±17°Max. oscillation angle of front axle±15°Max. oscillation angle of balance box15Frame articulation angle±27°Min. turning radius using articulation7.3mBiadeMaximum lift above ground450mmMaximum depth of cutting500mmMaximum blade position angle90°Blade cutting angle28°-70°Circle reversing rotation360°Moldboard width X height4270×610mm
