Kw18 Mini Excavator Small Digger Crawler 1.8 Ton for Sale
Henan Tarzan Industrial Co., Ltd.- Condition：New
- Rated Load：1-3t
- Walking Mode：Crawler
- Type：Small Loader
- Transport Package：Nude
- Specification：Customized
Base Info
- Model NO.：KW18
- Trademark：Dongfeng
- Origin：China
- HS Code：8429510000
- Production Capacity：500 Units Per Month
Description
MODELKW18 OPERATING WEIGHT 1800 kg CUBE CAPACITY 0.1 m³ Engine Engine power 22.1 kw Engine rated speed 2200 rpm Hydraulic system pressure 16 MPa Gradeability 30 ° Ground pressure 23×10³ N/m² Walking speed 2 Km/h Maximum traction force 11.5 KN Platform rotation speed 10 r/min DIMENSION A total length 3600 mm Chassis Length 2200 B overall width 1300 mm C total height 2300 mm D platform turning radius 1270 mm E Track length 1890 mm F Ground clearance 260 mm G boom end height 960 mm H platform outer width 1200 mm I Engine hood height 1390 mm J Platform height from the ground 810 mm K track width 275 mm WORKING RANGE A maximum digging height 2800 mm B maximum unloading height 2200 mm C maximum digging depth 2200 mm D maximum digging radius 4200 mm D1 Maximum ground level digging distance 3100 mm E Digging radius of maximum digging height 3800 mm F minimum radius of gyration 2300 mm G bulldozer maximum bucket depth 150 mm H bulldozer maximum lifting height 270 mm
