8ton Crawler Excavator with CE Certificate
Henan Tarzan Industrial Co., Ltd.- Type：Crawler Excavator
- Usage：Marine Excavator
- Bucket：Grab Shovel
- Transmission：Hydraulic Transmission
- Drive Type：Electric Drive
- Bucket Capacity：0.1~0.5m³
Base Info
- Model NO.：Excavator
- Size：Medium-Sized
- Certification：CE
- Condition：New
- Engine Type：Yanmar
- Wheelbase：2200
- Rotating Speed：9
- Ground Pressure：39
- Transport Package：Standard Package
- Specification：5830x2160x2600
- Trademark：xiniu
- Origin：China
- HS Code：8429590000
- Production Capacity：2000units,Month
Description
Company ProfileFounded in 2017, HENAN TARZAN INDUSTRIAL CO., LTD., specializes of international export business for commercial & passenger vehicles, construction machinery, spare parts and so on. With open mind, global perspective, strengthen with foreign famous enterprises and domestic industry leading enterprises of the joint venture cooperation during the recent years, and now our cooperating manufacturing base covering the concrete mixing station, cranes, wheel loaders, excavators, forklifts, road rollers and spare parts, and other wide range and variety of products series, with high quality, excellent service marketing strategy, we have been in the international business with significant market share.
Contact information : Henan Tarzan Industrial Co.,Ltd.
Using YANMAR engine, in-line four strokes, low fuel consumption, environmental protection, convenient repair and maintenance.
Electronic monitoring using a dot matrix type advanced multifunctional large screen liquid crystal display, electronic throttle control system has the function of throttle control, automatic idle speed, overheat protection, speed acquisition.
Give full consideration to reduce the working oil consumption, to obtain maximum efficiency in all kinds of work site operation.
Imported original hydraulic parts, quality is reliable and stable, working efficiency is high.
Based on the strong and durable key parts and international quality chassis configuration, operation stability is stronger.
The machine adopted new type cab with wide field of vision, new seat, and automatic regulated air conditioning system, make the operation flexible and comfortable.
The concept of low noise, ensure the operator to manipulate more comfortable and safety.
| Main dimension | Unit | |
| A wheelbase | mm | 2200 |
| B Total length of track | 2750 | |
| C Platform back turning radius | 720 | |
| D Platform back turning radius | 1570 | |
| E Chassis width | 2150 | |
| F Track width | 400 | |
| G Chassis ground clearance | 345 | |
| H Track height | 650 | |
| I Transport length | 5830 | |
| J Height of cab | 2600 | |
| K Transport width | 2160 |
| Operating range | Unit | |
| A Max.digging radius on ground | mm | 6140 |
| B Max. Digging depth | mm | 3440 |
| C Max. Digging height | mm | 6220 |
| D Max. Dumping height | mm | 4540 |
| E Max.Vertical digging depth | mm | 3190 |
| F Max.Rotation Radius | mm | 2180 |
| G Max. Upgrade height of dozer blade | mm | 335 |
| H Max. Digging depth of dozer blade | mm | 440 |
| Specification | Unit | |
| Operation weight | kg | 7450 |
| Bucket capacity | m³ | 0.3 |
| Rate power | Kw/pm | 36.2kw /2100 |
| (/)Traveling speed(high/low) | km/h | 3.7/2.3 |
| Rotating speed | rpm | 9 |
| Climbing ability | / | 35° |
| Ground pressure | Kpa | 39 |
| Bucket digging force | KN | 52 |
| Arm digging force | KN | 38 |
| MAIN DIMENSIONS | UNIT | X80-E |
| (Overall Dimension ) | mm | 5830x2160x2600 |
| (Cab Dimension ) | mm | 1300x950x1520 |
| (Bucket Capacity) | cbm | 0.3 |
| SYSTEM CONFIGURATION | ||
| (Engine Type) | YANMAR | |
| (No. of Cylinders/Type) | 4 cylinder / in line | |
| (Starting Type) | Electric 12V | |
| (Hydraulic Main Pump) | Rexroth/Jingken | |
| (Hydraulic System Pressure) | MPa | 22 |
| (Hydraulic System Flow) | L/min | 150 |
| (Pilot Pump) | Rexroth/Jingken | |
| (Valve) | Rexroth/Jingken | |
| (Swing Motor) | EATON | |
| (Travel Motor) | EATON | |
| (Working Fuel Consumption) | L/h | 7.08 |
| (Diesel Oil Tank Capacity) | L | 167 |
| (hydraulic Oil Tank Capacity) | L | 125 |
| OPERATION RANGE | ||
| (Boom Length) | mm | 3300 |
| (Arm Length) | mm | 1750 |
| (Radius to Rear End) | mm | 1570 |
| (Ground Clearance) | mm | 345 |
| (Blade Dimension) | mm | 2024x345 |
| (Standard Machine With A/C) | A/C | Standard |
| (Packing Way) | 2 units in a 40HQ | |
| (Passed Certificates) | CE ISO |
