24ton Hydraulic Road Construction Excavator with Isuzu Engine

Shanghai YingXin World Machinery Co., Ltd.
  • Type：Crawler Excavator
  • Usage：GM Excavator
  • Bucket：Shovel
  • Transmission：Hydraulic Transmission
  • Drive Type：Internal Combustion Drive
  • Bucket Capacity：1.0~1.5m³

Base Info

  • Model NO.：w2245
  • Size：Medium-Sized
  • Certification：CE, ISO9001: 2000
  • Condition：New
  • Road Construction Excavator：Construction Excavator
  • Hydraulic Crawler Excavator：Hydraulic Excavator
  • Tractor Excavator：Tract Type Excavator
  • Hitachi Excavator：C320 Excavator
  • Operating Weight：23900(Kg)
  • Crawler Ground Length：34639(mm)
  • Max.Vertical Wall Digging Depth：6899(mm)
  • Max.Digging Depth：6940(mm)
  • Max.Dumping Clearance：6786(mm)
  • Max.Digging Height：9680(mm)
  • Transport Package：in Loose
  • Specification：CE, ISO
  • Trademark：world
  • Origin：China
  • HS Code：84295212
  • Production Capacity：500PCS,Year

Description

Engine SystemBrand & OriginISUZU(Japan)ModelCC-6BG1TRPRated Power125/2100 kw/rpmMax. Torque637.9/1800 Nm/rpmIdling Speed950rpmEngine Displacement6.494 LCylinder No.-Bore/Stroke6-105mmx125mmEngine Oil Capacity17.5~21.5LFuel Tank Capacity394 LFuel Consumption Rate237 g/kw.h or less Bitmap

Working SpecificationsOperating weight 23900(Kg) Bucket capacity 1.1(m3) Max. breakout force (1)Bucket digging force 150(KN) (2)Arm digging force 119(KN) Max.digging height 9680(mm) Max.dumping clearance 6786(mm) Max.digging depth 6940(mm) Max.vertical wall digging depth 6899(mm) Max.digging reach 10229(mm) Min.front swing radius 2940(mm) Max.pulling force 212(kN) Max.travel speed(double modes) 5.8/3.8(km/h) Max.grade ability 70%  Overall dimensionsLength(with bucket on ground) 13144(mm) Width(600mm crawler shoes ) 2890(mm) Bucket width 1256(mm) Ground length (in transportation) 10120(mm) Height(To the top of the boom) 3040(mm) Height(To the top of the cab) 2920(mm) Counter weight ground clearance 1090(mm) Track gauge 2420(mm) Tail swing radius 2915(mm) Min. ground clearance 460(mm) Rotating platform width 2890(mm) Counter weight height 2031(mm) Crawler teeth thickness 26(mm) Reach from swing center to tail 2914(mm) Crawler ground length 3463(mm) Standard arm length 2950(mm) overall length of crawler 4260(mm)
