• Model NO.：SWG165-II
• Engine Power：165 HP
• Blade Width：3660 mm
• Blade Cycling：360 Degree
• Operating Weight：14500kg
• Brand：Sinoway
• Warranty：12 Months
• Transport Package：Nude
• Specification：ISO9001
• Trademark：SINOWAY
• Origin：China
• HS Code：84314990
• Production Capacity：2000 PCS Per Year

EngineModelCummins 6BT5.9TypeDirect injection,turbocharged,water cooledRated power125kwRated speed2100rpmRated fuel consumption201g/kw·hTransmission SystemType3 elements,single stage(ZF technology)Torque ratio2.52Cooling typePressure oil circulatingGear box typePower shift(ZF technology)Gear shifts(Forward/Reverse)F6/R3Traveling speed(km/h) Forward/Reverse I6.5/6.5Forward/Reverse II11.4/14.6Forward/Reverse III14.6/30Forward IV24.8Forward V30Forward VI49.2AxleDrive typeFour wheel drive(6X4)Front axle ground clearance610mmFront wheel lean32°(L/R)Oscillation±15°Drive axleImported No SPIN differentialSteering SystemFront wheel steering angle49°(L/R)Turning radius10.0m(non leant wheel) 10.4m (leant wheel)Articulated steering angle26°(L/R)Drive typeDual action cylinderWorking EquipmentControl systemHydrostatic drive systemHydraulic pumpHigh pressure gear pumpControl valveHUSCOControl pressure18MPaHydraulic oil cylinderHYUNDAIMax. tractive force78.5KNGround penetration535 mmBlade width3660 mmBlade cycling360°Max. bank cutting angle90°(L/R)Braking SystemService brakeHydraulic assisted actuate drum brakeParking brakeFlexible control and inner-expanding drum brakeDimensionsOverall length8630 mmOverall width(wheel outside)2600 mmOverall height3370 mmWheel base6100 mmFront tread2120 mmRear treads 2120 mm Tyre size 17.5-25 Service Capacities  Fuel tank 350L Engine crank case 27L Hydraulic tank 70L Gear box 45L Rear axles 18L Balance box 42L(each) Worm gear case 3L Tandem Drive  Type Swing type with roller chain transmission Speed ratio 18.03
