• Model NO.：L58-B3
• Type：Medium-sized Loader
• Operating Weight (Kg)：18000
• Engine Model：Wp10
• Rated Power/Rated Speed (Kw/Rpm)：162,2000
• Forward Speed (Km/H)：F1:0-13, F2:0-40
• Center Distance of Track (mm)：2000
• Fuel Tank (L)：450
• Transport Package：Nude
• Specification：8460*3050*3540 mm
• Origin：Shandong, China
• HS Code：8429510000
• Production Capacity：100,Month

Basic Info.

Model NO. L58-B3 Type Medium-sized Loader Operating Weight (Kg) 18000 Engine Model Wp10 Rated Power/Rated Speed (Kw/Rpm) 162/2000 Forward Speed (Km/H) F1:0-13, F2:0-40 Center Distance of Track (mm) 2000 Fuel Tank (L) 450 Transport Package Nude Specification 8460*3050*3540 mm Origin Shandong, China HS Code 8429510000 Production Capacity 100/Month

Product Description

SHANTUI 5 ton 162 KW Wheel Loader (L58-B3) with BUCKET CAPACITY 3 CBM
Product OverviewPower System

Weichai engine exclusively customized for Shantui conforms to the China-II non-road machinery emission regulation, featuring high intelligence and efficiency, high parts interchangeability, and low maintenance cost.

 Driving/Riding Environment

The new generation cab with all-new design optimization and large door structure is mold formed to guarantee broader vision and more fashionable appearance.

The framework structure in four sides enlarges the interior space by >10% to ensure high safety, comfort, and reliability.

The extensively adjustable seat provides the driver with the most comfortable operation;

The locations of joysticks, pedals, and seat are reasonably arranged to achieve higher operating comfort.

The standard radio and audio provides more abundant personalized driving/riding experience and guarantees the comfortable and safe driving/riding environment.

Operating performance

The locations of joysticks, pedals, and seat are reasonably arranged to achieve higher operating comfort. The optional pilot control system features flexible and convenient operations.

Convenient maintenances

The grease extraction pipelines are added and the maintenance locations (Including filter elements) are optimized to ease the daily repairs and maintenances.

Parameter

Parameter name	L58-B3 SG (Sand&stone version)	L58-B3 SG (Coal version)	L58-B3 MH (Ore version)
Performance parameters
Operating weight (Kg)	17200	18000	17650
Maximum dumping height (mm)	3200 (Standard boom) 3450 (Extended boom) 3700 (Long Boom)	3210 (Extended boom) 3420 (Long Boom)	3215 (Standard boom) 3260 (Extended boom)
Dumping reach (mm)	1230 (Standard boom) 1200 (Extended boom) 1270 (Long Boom)	1395 (Extended boom) 1510 (Long Boom)	1125 (Standard boom) 1310 (Extended boom)
Maximum breakout force (kN)	≥185	≥185	≥185
Total cycle time (s)	10.5	10.5	10.5
Engine
Engine model	WP10	WP10	WP10
Rated power/rated speed (kW/rpm)	162/2000	162/2000	162/2000
Overall dimensions
Overall dimensions of machine (mm)	8100*3030*3540	8460*3050*3540	8160*3075*3540
Driving performance
Forward speed (km/h)	F1:0-13, F2:0-40	F1:0-13, F2:0-40	F1:0-13, F2:0-40
Reversing speed (km/h)	R:0-15	R:0-15	R:0-15
Chassis System
Wheelbase (mm)	3300	3300	3300
Tank capacity
Fuel tank (L)	230	230	230
Working device
Rated bucket capacity (m³)	3	4	2.5
Rated loading capacity (t)	5	5	5
