Shantui Wheel Road Roller Sr30t-3 30 Ton Road Roller for Sale
Maxizm Construction Machinery (Qingdao) Co., Ltd.- After-sales Service:Free Spare Parts
- Warranty:Free Spare Parts
- Type:Road Roller
- Working Method:Wheeled
- Axle:Biaxial Dual-Drum
- Grinding Wheel Type:Tire Grind
Base Info
- Model NO.:SR30T-3
- Compaction Depth:40cm
- Engine Type:Diesel Engine
- Travel Speed:10.4
- Centrifugal Force:290,180
- Certification:EPA, CS, CE, RoHS, ISO 9001:2000, ISO 9001:2008
- Condition:New
- Operating Weight:20000kg
- Exciting Force (Kn):380,275
- Vibration Frequency (Hz):29,35
- Nominal Amplitude (mm):2,1.0
- Theoretical Gradeability:48%
- Driving Performance:6232*2422*3372mm
- Forward Speed (Km/H):F1: 0~5.2 ,F2: 0~7.2 ,F3: 0~12.7
- Transport Package:Nude
- Specification:6240*2300*3100 mm
- Trademark:SHANTUI
- Origin:China
- HS Code:8429401100
- Production Capacity:50000
Description
Basic Info.
Model NO. SR30T-3 Compaction Depth 40cm Engine Type Diesel Engine Travel Speed 10.4 Centrifugal Force 290/180 Certification EPA, CS, CE, RoHS, ISO 9001:2000, ISO 9001:2008 Condition New Operating Weight 20000kg Exciting Force (Kn) 380/275 Vibration Frequency (Hz) 29/35 Nominal Amplitude (mm) 2/1.0 Theoretical Gradeability 48% Driving Performance 6232*2422*3372mm Forward Speed (Km/H) F1: 0~5.2 ,F2: 0~7.2 ,F3: 0~12.7 Transport Package Nude Specification 6240*2300*3100 mm Trademark SHANTUI Origin China HS Code 8429401100 Production Capacity 50000Product Description
Shantui Wheel Road Roller SR30T-3 30 Ton road roller for sale
product description
- Shangchai SC8D156G2B1 turbocharged diesel engine is a product of wisdom jointly developed by Shanghai Diesel Engine Co., Ltd. and Austrian AVL, featuring prominent performances, high reliability, and good fuel economy, and is one mainstream installed engine in China's construction machinery industry.
- The drive system adopts the hydraulic torque converter with automatic stepless speed change performance and power shift transmission for transmission of power, featuring steady startup, flexible gearshift operations, and great reduction of operator's labor strength.
- The front four-tire and rear five-tire arrangement is adopted to achieve overlapped compacting effect in width-base plane, with the ground pressure up to 480KPa.
The compacting effect can be effectively controlled by adding/removing the counterweights to improve the working efficiency. The oscillating mechanism is adopted for the front wheels to effectively and uniformly compacting the uneven working face and improve the working efficiency. - The independent control system with two steering wheels and two seats and the electric gearshift joystick feature flexible reversing operations and high convenience and reliability.
- The design of streamline hood works with two-sided operation and wide-angle rearview mirrors to provide the operator with a broad visual field.
Parameter name | SR30T |
Performance parameters | |
Operating weight (Kg) | 30000 |
Exciting force (KN) | - |
Vibration frequency (Hz) | - |
Nominal amplitude (mm) | - |
Ground pressure (KPa) | 200-460 |
Gradeability (%) | 20 |
Engine | |
Engine model | SC7H |
Rated power/rated speed (kW/rpm) | 132/1800 |
Overall dimensions | |
Overall dimensions of machine (mm) | 5060*2892*3338 |
Driving performance | |
Forward speed (km/h) | F1:0-8,F2:0-18 |
Reversing speed (km/h) | R1:0-8,R2:0-18 |
Chassis System | |
Wheelbase (mm) | 3840 |
Tank capacity | |
Fuel tank (L) | 180 |
Working device | |
Compacting width(mm) | 2750 |
