Mini Bull Dozer High Efficiency Crawler Sanitation Bulldozer with U-Blade
Shandong Eterne Machinery Co., Ltd.- After-sales Service：Lifetime Online Support
- Warranty：1 Year
- Type：Universal Type
- Transmission：Power Transmission
- Walking Mode：Crawler
- Load and Unload Method：Front Discharge
Base Info
- Model NO.：ET-160
- Engine Power：147~515kw
- Certification：CE
- Condition：New
- Color：Yellow
- Name：Bulldozers
- Machine Weight：17.5ton
- Dozing Capacity：4.7
- Hydraulic Pump Brand：Permco or Linde
- Hydraulic Cylinder Brand：Ruich
- Hydraulic Valve Brand：Hydraforce
- Transport Package：in Container
- Specification：4700,925,1560mm
- Trademark：ET
- Origin：Shandong, China
- HS Code：8431420000
- Production Capacity：1000set,Year
Description
Main ParametersModel ET-160 ET-220 ET-320 ET-160TL Engine model Weichai WP10G178E355 Cummins NT855-C280S10 Cummins NTA855-C360S10 Weichai WP10G178E355 Rated power(kw/rpm) 131/1850 175/1800 235/2000 131/1850 Displacement(L) 9.726 14.01 14.01 9.726 Max.torque(N.m/rpm) 830/1000-1200 1030/1250 1440/1400 830/1000-1200 Operating weight(Kg) 17000 23500 37200 18300 kg Dimension(no ripper)(mm) 5140*3388*3032 5492*3726*3742 6885*4128*3645 5256*4153*3072 Min ground clearance(mm) 405 405 500 492 Ground pressure(MPa) 0.067 0.072-0.077 0.105/0.09/0.078 0.026 Track shoe width(mm) 510 560/610/660 560/660/760 1100 Track gauge(mm) 1880 2000 2140 2300 Dozing capacity( m3) 4.55 6.4 10 3.85 Blade width(mm) 3390 3725 4130 4145 Blade height(mm) 1150 1315 1590 962 Maxdrop below ground(mm) 540 540 560 488 Pitch(mm) 203.2 216 228 203.2 Quantity of track link 37 38 41 Quantity of Carrier rollers 4 4 4 2 Quantity of Track rollers 12 12 14 7 Max pressure(MPa) 14 14 14 14 Discharge(L/min) 213 262 355 227 Max tractor force(KN) 146 202 280 Grade ability(°) 30 30 30 30 Forward(km/h) 3.29/5.82/9.63 3.6/6.5/11.2 3.6/6.6/11.5 2.67/3.76/5.41/7.62/11.13 Reverse(km/h) 4.28/7.59/12.53 4.3/7.7/13.2 4.4/7.8/13.5 3.48/4.9/7.05/9.92
1. Cummins engine gives you the power and reliability you need. Improved fuel economy over the previous model with strong torque output and low fuel consumption gives you excellent overall fluid efficiency.
2. The planetary power shift transmission with forced lubrication and the hydraulically assisted steering system achieve light operations of the machine and feature high transmission power and high productivity.
3. Quality undercarriage parts including rollers, tracks and chains ensures the stable and good performance of the dozer. Different types of the tracks can meet different working condition, like dryland, wetland and rock conditions.
4. Roomier cab with a wider entry offers added comforts like a adjustable seat, manually adjustable armrests, larger cup holder and auxiliary power port. Smoother shifting and a quieter.
5. The hexahedral cabin for standard type dozer and different types of cabins can be equipped, like ROPS cabin, forest logging anti-roll cabin etc.
6. The standard straight tilt blade features powerful cutting force and variety of shovels can be optional, like rock shovel, U-shaped shovel, semi-U shaped shovel, sanitation shovel etc.
7. Variety devices can be equipped with crawler bulldozer, like three tooth ripper, winch.
Shandong Eterne Machinery Co., Ltd. is a modern enterprise comes from Weifang city, Shandong Province, China, which is integrating R & D, production and service including mining equipment and woodworking equipment. The related companies are Ninjing Country Wanfa Woodworking Machinery Co.,Ltd.(Wanfa), Weifang Jintong Envrionment Protection Company (Jintong).
This story started from a rural young man determined to change his poor life. He believes life can be better with no spare efforts and the desire of change. Mr.Liu with humble education and background from the village, has inborn interested in machinery and never give-up spirit, finally built his own company in Ningjin Country- "Home Of Chinese Furniture".
As time going, he enlarged the business and invested mining equipment business (Jintong company)after carefully examining which produce dredger, gold mining equipment, aquatic weed harvester, sand washing equipment etc.
Our products have been sold all over the country and exported to more than 50 countries, such as Bangladesh, Philippines, Indonesia, Malaysia, Suriname, Bolivia, Ecuador, Nigeria, South Africa, Mali, Tanzania, etc. We can independently design and develop reasonable and feasible product plans according to the use requirements of customers and their special geographical environment.
We will adhere to the enterprise tenet of creating value with quality, pursuing perfection with service and seeking development with reputation to provide our customers with high quality products and perfect services.
ET Interprise Tenet: strive for survival by quality and seek development by innovation.
ET Service Concept: Honesty and adhering client-first.
ET Brand Goal: Make first-class quality and service.
We are willing to create brilliant tomorrow with friends domestic and abroad! Thank you.
10.FAQ
1. Cummins engine gives you the power and reliability you need. Improved fuel economy over the previous model with strong torque output and low fuel consumption gives you excellent overall fluid efficiency.
2. The planetary power shift transmission with forced lubrication and the hydraulically assisted steering system achieve light operations of the machine and feature high transmission power and high productivity.
3. Quality undercarriage parts including rollers, tracks and chains ensures the stable and good performance of the dozer. Different types of the tracks can meet different working condition, like dryland, wetland and rock conditions.
4. Roomier cab with a wider entry offers added comforts like a adjustable seat, manually adjustable armrests, larger cup holder and auxiliary power port. Smoother shifting and a quieter.
5. The hexahedral cabin for standard type dozer and different types of cabins can be equipped, like ROPS cabin, forest logging anti-roll cabin etc.
6. The standard straight tilt blade features powerful cutting force and variety of shovels can be optional, like rock shovel, U-shaped shovel, semi-U shaped shovel, sanitation shovel etc.
7. Variety devices can be equipped with crawler bulldozer, like three tooth ripper, winch.
Shandong Eterne Machinery Co., Ltd. is a modern enterprise comes from Weifang city, Shandong Province, China, which is integrating R & D, production and service including mining equipment and woodworking equipment. The related companies are Ninjing Country Wanfa Woodworking Machinery Co.,Ltd.(Wanfa), Weifang Jintong Envrionment Protection Company (Jintong).
This story started from a rural young man determined to change his poor life. He believes life can be better with no spare efforts and the desire of change. Mr.Liu with humble education and background from the village, has inborn interested in machinery and never give-up spirit, finally built his own company in Ningjin Country- "Home Of Chinese Furniture".
As time going, he enlarged the business and invested mining equipment business (Jintong company)after carefully examining which produce dredger, gold mining equipment, aquatic weed harvester, sand washing equipment etc.
Our products have been sold all over the country and exported to more than 50 countries, such as Bangladesh, Philippines, Indonesia, Malaysia, Suriname, Bolivia, Ecuador, Nigeria, South Africa, Mali, Tanzania, etc. We can independently design and develop reasonable and feasible product plans according to the use requirements of customers and their special geographical environment.
We will adhere to the enterprise tenet of creating value with quality, pursuing perfection with service and seeking development with reputation to provide our customers with high quality products and perfect services.
ET Interprise Tenet: strive for survival by quality and seek development by innovation.
ET Service Concept: Honesty and adhering client-first.
ET Brand Goal: Make first-class quality and service.
We are willing to create brilliant tomorrow with friends domestic and abroad! Thank you.
10.FAQ
Q1:What about the delivery?
We can offer our equipment by containers or bulk ship, just depend on your actual request.
Q2:What is the warranty?
We provide 1 year warranty and free repair if quality problems emerge within warranty peride.
Q3:What's the payment methode?
We can accept T/T, L/C, WESTERN UNION and so on.
Q4:Is it factory?
Yes,we have our own factory.and welcome to visit our factory.thanks
Q5.Whether it can be customized according to customer requirements?
Yes,we can design according to customer's requirement,we have many kinds of model.you can choose the suitable one.
