Hot Sale Solar Crawler Hydraulic Pile Driver Machine
Ji Ning Hengwang Mining Machinery Co., Ltd.- After-sales Service：Yes
- Warranty：Yes
- Type：Vibration Piling Machine
- Pressure Pile Driver Type：Hydraulic Pile Driver
- Pile Hammer Type：Hydraulic Hammer
- Power Source：Diesel
Base Info
- Model NO.：HWL390H
- Motor Power：85kw
- Noise：With Noise
- Certification：CE, RoHS
- Condition：New
- Model：Hwl300h
- Drilling Diameter(DTH Hammer)(mm)：90-400
- Air Consumption (M3/Min)：10-26
- Drill Pipe Diameter(mm)：76,89
- Rock Hardness(F)：6-20
- Drilling Diameter(Auger)(mm)：Maximum 400
- Drilling Depth(M)：20
- Auger Diameter(mm)：130-400
- One Thrust Stroke (mm)：2600
- Pitch Angle of Slide Frame (°)：120
- Slide Frame Swing Angle(°)：Left and Right Total 40
- The Angle of The Drill Arm Swing (°)：Left and Right Total 50
- Rotating Speed(R/Min)：0-110
- Slope Working Angle (°)：45
- Working Dimension (L*W*H)(mm)：3500*2200*4500
- Specification：4500*2500*2800mm
- Trademark：Hengwang
- Origin：Shandong
- Production Capacity：100PCS ,Month
Description
Drilling diameter(DTH hammer)(mm)
90-400
Drilling depth(m)
1-100
Air consumption (m3/min)
10-26
Working wind pressure (Mpa)
0.7-1.6 (medium-pressure) /1.6-2.46 (high pressure)
Drill Pipe Diameter(mm)
76/89
Rock hardness(F)
6-20
Drilling diameter(auger)(mm)
Maximum 400
Drilling depth(m)
20
Auger diameter(mm)
130-400
One thrust stroke (mm)
2600
Pitch Angle of slide frame (°)
120
Slide frame swing Angle(°)
left and right total 40
The Angle of the drill arm swing (°)
left and right total 50
rotating speed(r/min)
0-110
Slope working angle (°)
45
Working dimension (L*W*H)(mm)
3500*2200*4500
Shipping dimensions
4500*2500*2800
Weight (Kg)
7300
Traveling speed (km/h)
0-2.5
Rated power (kw)
85
Max.width (mm)
2800
Expansion height of one side track (mm)
1200
