XCMG Official Xc740K Chinese Mini Loader Skid Steer
Xuzhou Construction Machinery Group Co., Ltd.- After-sales Service：Overseas Service Center Available
- Warranty：1year
- Certification：TUV, UL, ISO, RoHS, CE
- Condition：New
- Rated Load：750kg
- Transmission：Hydraulic Transmission
Base Info
- Load and Unload Mode：Front Discharge
- Walking Mode：Wheeled
- Type：Small Loader
- Rated Bucket Capacity：0.45m3
- Dumping Reach：575mm
- Operating Weight：3140kg
- Rated Power：49.3,36.8 HP,Kw
- Transport Package：Comply with Export Packaging Requirements
- Specification：3270*1807*1970mm
- Trademark：XCMG
- Origin：Xuzhou, Jiangsu, China
- HS Code：87059091
- Production Capacity：1000,Year
Description
Overview
Product Description
Advantages and Highlights:
1. Strong and Efficient Power Transmission System
* The renowned brand engine equipped features strong power, ultra-low emission, and higher fuel efficiency.
* The static hydraulic drive technology adopted features stable drive and high efficiency and reliability.
* The fully-sealed sprocket case and high strength chains feature automatic lubrication and maintenance-free.
2. Incomparable Multi-Functionalities
The international interchangeable quick-change coupling enables the change of tens of attachments, including sweeper, planer, breaking hammer, and ditcher, rapidly and conveniently.
3. Solid and Reliable Design
The integral frame adopted features compact structure and high firmness and reliability. All critical structural parts are optimized through finite element analysis to realizereasonable stress distribution.
4. Flexible Operations
The bucket can automatically maintain level status during lifting to prevent scattering of material and improve working efficiency.Product Parameters ParametersUnit XC740K Rated load kg 750 Tipping load kg 1500 Operating weight kg 3140 Maximum breakout force kN 18 Engine Manufacturer Xinchai Model 4D27G31 Rated power Hp/kw 49.3/36.8 Rated speed rpm 2500 Cooling mode Water-cooling Performance parameter Operation mode Mechanical & multi-function electronic control Tire standard 10-16.5 Maximum speed Km/h 14 Hydraulic system Hydraulic flow rate L/min 62.5 Optional large flow -- Hydraulic pressure bar 200 A Maximum operating height mm 3878 B Bucket hinge pin height mm 3057 C Cabin top height mm 1960 D Maximum horizontal height of bucket bottom mm 2851 E Length without bucket mm 2533 F Length with bucket mm 3310 G Toppling angle ° 40 H Maximum unloading height mm 2375 K Ground-bucket angle ° 30 L Rotating angle of bucket at highest point ° 83 J Unloading distance mm 575 M Wheel base mm 1027 O Departure angle ° 25 P Ground clearance mm 183 R Front radius of turning circle (without bucket ) mm 1183 S Front radius of turning circle (with bucket) mm 2066 T Rear radius of turning circle mm 1564 U Length of tail mm 1005 V Wheel track mm 1380 W Tire edge width mm 1640 X Bucket edge width mm 1800 Bucket capacity (stacking height) m3 0.45 Bucket capacity (tiling) m3 0.35 Diesel tank capacity L 80 Capacity of hydraulic oil tank L 60
Company Profile
XCMG XC740K with strong power and rich attachments, the XCMG skid-steer loader can better adapt to the operations in narrow space and is an ideal tool for road construction, municipal maintenance, port handling, garden maintenance, and pasture production, featuring low operation cost and remarkable economic benefits.
Advantages and Highlights:
1. Strong and Efficient Power Transmission System
* The renowned brand engine equipped features strong power, ultra-low emission, and higher fuel efficiency.
* The static hydraulic drive technology adopted features stable drive and high efficiency and reliability.
* The fully-sealed sprocket case and high strength chains feature automatic lubrication and maintenance-free.
2. Incomparable Multi-Functionalities
The international interchangeable quick-change coupling enables the change of tens of attachments, including sweeper, planer, breaking hammer, and ditcher, rapidly and conveniently.
3. Solid and Reliable Design
The integral frame adopted features compact structure and high firmness and reliability. All critical structural parts are optimized through finite element analysis to realizereasonable stress distribution.
4. Flexible Operations
The bucket can automatically maintain level status during lifting to prevent scattering of material and improve working efficiency.Product Parameters Parameters
