• Model NO.：ZL50GN
• Load and Unload Mode：Front Discharge
• Walking Mode：Wheeled
• Type：Small Loader
• Engine Model：Wd10g178e25;131kw
• Track Shoe Width：510mm
• Core Components：Pressure Vessel, Engine, Pump
• Marketing Type：Ordinary Product
• Transport Package：Nude Packing
• Specification：9570*2800*3140mm
• Trademark：Sinomada
• Origin：China
• HS Code：84291190
• Production Capacity：1000 Units, Month

Overview Product Description





Product Overview

ZL50GN wheel loader is the latest cross-generation product developed by  on the basis of the globalized technologic resources.

Focusing on the customer value and emphasizing the customer experiences,  new generation loader boasts outstanding advantages (such as efficiency) in the fields of engineering constructions, aggregate yards, and coal logistics.



Performance Highlights

The 160kN traction force and ≥3.5m high dumping capacity handle the severe conditions with ease.

≥7,500kg lifting capacity and 170kN breakout force handle all kinds of materials with ease.



Strong power

 patented technology Heavy-duty energy-conservation transmission and torque converter assembly

Enhanced heavy-duty drive axle of outstanding performances

The design of cab and access passages is ergonomically optimized to create the best driving and riding experience for the operator from the first touch of the machine.

Human-oriented design Guarantee safety and reduce fatigue

Long-tested super-strong heavy-duty structural parts

Frame structure of super-strong carrying capacity

Secure and reliable frame hinge joints

Excellent quality power and drive systems

Diversified bucket design

High strength wear-resistant bucket design

Application of high strength wear-resistant material

Specially enhanced critical portions

Optimized boom hinges

Higher convenience

Various attached toos meeting requirements of different working conditions



Product Parameters



ItemSpecificationUnitRated operating load5000kgBucket capacity2.5~4.5m³Machine weight17500±300kgDump clearance at maximum lift3100~3780mmReach at maximum lift1100~1220mmWheel base3300mmTread2250mmMax.breakout force175±5kNHydraulic cycle time-raise6sTotal hydraulic cycle time10.5sMin. turning radius over tyres5925±50mmArticulation angle38°Gradeability30°Tyre size23.5-25-16PR Overall machine dimension L×W×H8225×3016×3515 mmModelWD10G220E21/ SC11CB220G2B1 Rated Power162KwTravel speedgear(F/R)13/17km/hgear(F)41km/hDetailed Photos
