• Model NO.：L39-B3
• Load and Unload Mode：Front Discharge
• Walking Mode：Wheeled
• Type：Medium-sized Loader
• Transport Package：Nude Package
• Specification：10ton
• Trademark：SINOMADA
• Origin：China
• HS Code：8429521200
• Production Capacity：50000pieces,Year

Basic Info.

Model NO. L39-B3 Load and Unload Mode Front Discharge Walking Mode Wheeled Type Medium-sized Loader Transport Package Nude Package Specification 10ton Trademark SINOMADA Origin China HS Code 8429521200 Production Capacity 50000pieces/Year

Product Description

Hydraulic Payloader Equipment Payloader Machine SHANTUI L39-B3Power System
Weichai low-speed energy-saving engine + 5t planetary gearbox drive system feature low fuel consumption, low failure rate, and high energy-saving and efficiency.
Driving/Riding Environment

The new generation cab with all-new design optimization guarantees broader vision and more fashionable appearance.

The framework structure in four sides guarantees high safety, comfort, and reliability.

The extensively adjustable seat provides the driver with the most comfortable operation;

It provides more abundant personalized driving/riding experience and guarantees the comfortable and safe driving/riding environment.

Operating performance
The locations of joysticks, pedals, and seat are reasonably arranged to achieve higher operating comfort. The optional pilot control system features flexible and convenient operations.

Parameter name	L39-B3 SG (Sandstone version)
Performance parameters
Operating weight (Kg)	10800
Maximum dumping height (mm)	3057 (Extended boom)3200 (Long Boom)
Dumping reach (mm)	906 (Extended boom)886 (Long Boom)
Maximum breakout force (kN)	≥105
Total cycle time (s)	8.9
Engine
Engine model	WP6
Rated power/rated speed (kW/rpm)	92/2000
Overall dimensions
Overall dimensions of machine (mm)	7275*2518*3235
Driving performance
Forward speed (km/h)	F1:0-12.5, F2:0-38
Reversing speed (km/h)	R1:0-16.4
Chassis System
Wheelbase (mm)	2900
Tank capacity
Fuel tank (L)	150
