• Model NO.：SE220
• Drive Type：Electric Drive
• Bucket Capacity：1.0~1.5m³
• Size：Medium-Sized
• Certification：CE, ISO9001: 2000
• Condition：New
• Displacement：5.9 L
• Power Output：112 Kw,1950 Rpm
• Travel Speed：3.3,5.1 Km,H
• Gradeability：70%
• System Capacity：400L
• Brake：Pressure Release Mechanical Braking
• Swing Speed：11.5 Rpm
• Transport Package：Nude
• Specification：9605*3080*3070mm
• Trademark：Shantui
• Origin：Shandong
• HS Code：8454314213
• Production Capacity：100units,Month

SE220 Technical specifications:

Minimum ground clearance: 468 mm

Overall length: 9549 mm

Operating weight: 21.6 t

Overall height: 3073 mm

Ground pressure: 47 kPa

Overall width: 2800 mm

ENGINE

Model

Cummins B5.9-C

Type

Water-cooled, 6-cylinder inline, turbocharged,air-to-air intercooled

Quantity of cylinders

6

Bore x stroke

102 x 120 mm

Displacement

5.9 L

Power output

112 kW/1950 rpm

Maximum torque

614 N·m/1500 rpm

HYDRAULIC
SYSTEM

Pump

Imported

Type

Variable double-piston pump

Maximum discharge flow

2 x 208 L/min

Boom, arm and bucket

31.9 MPa

Travel circuit

31.9 MPa

Swing circuit

25.5 MPa

TRAVEL
SYSTEM

Travel motor

Variable axial piston

Travel brakes

Lubricated double-disc

Parking brake

Pressure release

Travel shoes

2 x 46

Drawbar pulling force

201 kN

Travel speed

3.9~5.6 km/h

Gradeability

70% (35°)

Ground clearance

468 mm

CONTROLS & CABIN

Cabin

New ergonomic cab design strengthens the structure of the entire stamping with such features as: strong impact resistance, vibration damping pads, vibration absorption, comfortable seat with broad vision, leather-like and ABS & PVC plastic technology applied to interior, smooth contour lines of the outer surface & durability.

Controls

Two joysticks, two foot pedals, manual-/electronic-controlled throttle.Functions of two joysticks: digging & swinging.

Boom cylinder

120 x 85 x 1285 mm

Arm cylinder

135 x 95 x 1490 mm

Bucket cylinder

115 x 80 x 1120 mm

SWING SYSTEM

Swing motor type

Swash plate piston motor

Brake

Pressure release

Parking brake

Lubricated double-disc

Swing speed

11.9 rpm

Tail swing radius

2905 mm

BUCKET

Bucket capacity

Backhoe bucket 1.2 m3 (SAE)

Number of bucket teeth

5

Bucket width

1189 mm

Arm length

2919 m

Maximum digging reach/Maximum digging reach at ground level

9.839 m/9.64 m

Maximum digging depth/height

6.59 m/9.27 m

Maximum dumping height

6.490 m

Minimum swing radius

3.585 m
