• Model NO.：LGP400,700,80PL-E
• Condition：New
• Color：Green
• Mixer Volume：400L
• Mixer Output：6m3,H
• Mixer Power：7.5kw
• Agitator Volume：700L
• Agitator Rated Rev.：36rpm
• High Speed Pressure / Output：0-2.5MPa 0-80L,Min
• Low Speed Pressure / Output：0-4.5MPa 0-58L,Min
• Grout Station Weight：1350kgs
• Suitable W/C Ratio：≥0.5:1
• Warranty：12 Months
• Transport Package：Nude Package or According to Customer Requirement
• Specification：2500*2200*1730mm
• Trademark：Leadcrete
• Origin：China
• HS Code：8413509090
• Production Capacity：15sets,Month

Pump

Pressure / Output

High speed: 0-2.5MPa 0-80L/min

Low speed: 0-4.5MPa 0-58L/min

Power

15kw,50Hz,380V

Civil engineering - dam, tunnel, subway, mine, soil nailing wall, curtain, anchor, cable trench and anchor grouting;

Building structure - building and bridge repair, foundation reinforcement, slope support, soil compaction, terrg grouting;

Engineering - underwater foundation, offshore platform, coast foundation grouting reinforcement

Mine application - roadway reinforcement, backfill, waterproof grouting.

Acted as a grouting plant in the Pipe Jacking Machine

We have many kinds of grouting equipment for your reference, in order to recommend you more suitable models grouting equipment, please let us know clearly about your requirements:

1. what project will you do with grouting equipment? for dam, foundation treatment or micropile,etc?

2. what is the output and pressure of pump?

3. what is water cement ratio?

4. which engine do you prefer? electric motor or diesel engine?

if you want to know more about our grouting equipment, please feel free to contact with me.
