• Model NO.：SWWD340X
• Condition：New
• Color：Yellow
• Blade Type：Straight
• Blade Width：4436 mm
• Blade Height：1235 mm
• Tire Size：29.5r25
• Brand：Sinoway
• Model：Swwd340X
• Transport Package：Nude
• Specification：operating weight 30.3 ton
• Trademark：SINOWAY
• Origin：China
• HS Code：84314990
• Production Capacity：100 PCS Per Year

Basic Info.

Model NO. SWWD340X Condition New Color Yellow Blade Type Straight Blade Width 4436 mm Blade Height 1235 mm Tire Size 29.5r25 Brand Sinoway Model Swwd340X Transport Package Nude Specification operating weight 30.3 ton Trademark SINOWAY Origin China HS Code 84314990 Production Capacity 100 PCS Per Year

Product Description

Product Description

1. This machine adopts Cummins supercharged diesel engine which has a high reliability, well dynamic property, large power reservation, low fuel consumption, and electric extinction. It adopts a new type compound pre-filter to reduce early abrasion of the diesel engine.

2. The transmission parts adopt our company's bulldozer torque converter, transmission, axle that of military industry technology, which has a large circulation circle diameter, large torque ratio, wide high efficiency field, large traction torque, stable quality, high liability and long useful life.

3. The hydraulic pipeline adopts German DIN standard "Tapered - O" double sealing which has a good sealing performance and strong anti-leakage performance.

4. It is equipped with "maintenance-free battery + water-tight plug connectors + multi-function switch" to facilitate high safety, convenient operation and reliable performance of the complete vehicle electric system.

5. It adopts sealed and noise reduction cab that with wide field of view and in accordance with human engineering as well as top grade shock absorbing seats. The luxury internal trimmings as well as air conditioner, heater, and stereo facilitate a safe and comfortable operating environment.

Product Show

Specifications

Engine model	Cummins
Rated power	250kw
Gear box / Dive axle	German ZF
Tire size	29.5R25
Blade capacity	6.88m³
Blade width	4436mm
Blade height	1235mm
Max. drawbar force	270kN
Max. steering angle	40°
Max. digging depth	530mm
Max. lifting above ground	996mm
Max. tilt	1075mm
Travel speed
1st F/R	6.3km/h
2nd F/R	11.5km/h
3rd F/R	24km/h
4th F/R	31.5km/h
Wheelbase	3600mm
Tread	2400mm
Ground clearance	423mm
Min. turning radius	7404mm
Total length	7952mm
Total height	3805mm
Operating weight	30300kg
