• Model NO.：SD16F
• Engine Power：120kw
• Certification：CE
• Condition：New
• Color：Yellow
• L*W*H：5140*3388*3180 mm
• Ground Pressure：54kpa
• Transport Package：Nude
• Specification：17000kg
• Trademark：SINOMADA
• Origin：China
• HS Code：8426200000
• Production Capacity：100units,Month

item

SD16 National Two F (Forest Edition)

Performance parameter

Operating mass (kg)

17000

Engine net power (kw/hp)

120/160

Minimum turning radius (mm)

4571

Ground pressure (kpa)

54

engine

engine model

WD10G178E355/SC11CB184G2B1

emission

Country II

form

In-line, direct injection, water-cooled, four-stroke, turbocharged

Number of cylinders×bore×stroke (mm×mm)

6×126×130/6×121×152

Total displacement (L)

9.726/10.5

Rated power/rated speed (kw/rpm)

131/1850, 135/1850

Maximum torque (Nm/r/min)

830/(1000-1200), (792-894)/1300

Overall dimensions

Length (mm)

5140

Width (mm)

3388

Height (mm)

3180

Walking performance

Forward/reverse speed (km/h)

F1:0-3.29, F2:0-5.82, F3:0-9.63 R1:0-4.28, R2:0-7.59, R3:0-12.53

Climbing ability (deg)

30

Ground clearance (mm)

400

Transmission system

Transmission form

Hydraulic transmission

Number of gears F/R

March 3

Torque converter

Shantui self-made, single-stage single-phase three-element

Gearbox

Shantui self-made, power shift planetary transmission

Central transmission

Shantui self-made, spiral bevel gear single-stage deceleration

Steering clutch

Shantui self-made, wet multi-plate, spring compression, hydraulic control

Brake

Shantui self-made, wet, floating, belt, hydraulic power

Final drive

Shantui self-made, two-stage spur gear reduction, splash lubrication

Chassis system

Suspension method

Eight-shaped beam swing type, balance beam suspension structure

Track center distance (mm)

1880

Track shoe width (mm)

560/510/610

Grounding length (mm)

2635

Number of track shoes (single side/piece)

39

Chain track pitch (mm)

203

Number of supporting wheels (one side)

2

Number of supporting wheels (one side)

7

Working hydraulic system

Working pump

Quantitative gear pump

Working valve

Multi-way valve

Bore diameter of lifting cylinder (mm)

Φ110

Tilt cylinder bore (mm)

Φ160

Fuel tank capacity

Fuel tank (L)

315

Working hydraulic oil tank (L)

110

working equipment

Blade type

Angle shovel, straight tilt shovel

Blade width (mm)

Angle: 3970, Straight: 3388

Blade height (mm)

Angle: 1040, Straight: 1149

Working capacity (m³)

Angle: 4.3, Straight: 4.5

Blade lifting height (mm)

1095

Shovel depth (mm)

540

Winch type

Mechanical winch, hydraulic winch

Manipulation form

Walking manipulation

Mechanical manipulation

Work manipulation

Mechanical manipulation
