Ensign Brand Ce Approved Articulated 2.0 Ton Machine with Cummins Engine

Ensign Heavy Industries Co., Ltd.
  • Type：Universal Type
  • Transmission：Hydraulic Transmission
  • Walking Mode：Wheeled
  • Load and Unload Method：Front Discharge
  • Engine Power：147~515kw
  • Certification：CE, ISO9001: 2000

Base Info

  • Model NO.：YX657
  • Condition：New
  • Color：Orange
  • Warranty：2 Years
  • Delivery Time：10-30 Days
  • Engine：Df Cummins Engine
  • Power：160kw
  • Transport Package：1 Unit in 1*40hq
  • Specification：CE,SGS,EAC,ISO
  • Trademark：ENSIGN
  • Origin：Shandong Province, China
  • HS Code：84295100
  • Production Capacity：20000 Pieces,Year

Description

Bucket capacity2.4~4.5(standard bucket 3.0m3)Total cycle time(lift, dump& lower)≤11sRated load5000kgDump height/Dump angle3175/51mm/ °Overall operating weight16500kgDump distance/Dump angle1126/51mm/ °Max. traction force≥160kNMin. ground clearance445mmMax. breakout force≥190kNWheel base3200mmGrade ability30°Wheel tread2190mmMin. turning radius(outer side of the bucket)6652mmDeparture angle30°Min. turning radius(outer side of the tire)
 6038mmSteering angle(left & right)38°Specifications:
1.0 Engine Details
  (1) Model:Cummins 6CTA8.3-C215 Engine  Or
Shangchai SC11CB220G2B1
  (2) Engine Type:In-line arrangement,water-cooled,four-cycle diesel engine
  (3) Rated Power:160KW Or 162KW
  (4) Rated Speed:2200 r/min(rpm)
  (4) Fuel Consumption ration in
    Standard working condition:		235g/kw.H

2.0 Transmission System
  (1) Type:ZF electro-hydraulic transmission
  (2) Torque converter type:Single stage, 3 elements
  (3) Gears:4 forward, 3 reverse

3.0 Braking System
 (1) Service brake:Air-over-oil caliper disc
 (2) Parking brake:Manual pneumatic control drum brake

4.0 Steering system
(1) Type:Load sensing hydraulic
(2) Oil pump type:gear pump

5.0 Working device hydraulic system
(1) Hydraulic system pressure:18 Mpa
(2) Control type:Joystick
(3) Oil pump type:Gear pump

6.0 Tire
(1) Specification:23.5-25
(2) Tread pattern:L-3

7.0 Bucket
  (1) Bucket capacity:3.0 m3
  (2) Bucket type:Heavy-duty bolt on teeth
  (3) Rated Load:5000kg

Optional Configurations:
 Quick Hitch
  Joystick
  A/C
  Third function valve
  Longer arm
  Rops/Fops
  Tyre Chain
Optional Attachments:
 Rock Bucket
 Pallet/Grass Fork
 Grapple Forks/Wooden Forks
 Grapple Bucket
 Snow Bucket
 New Wooden Forks
 Hydraulic Snow Blade
 Sweeper
 Snow Blower
  4 In 1 Bucket

 We Are The Factory!
We Only Produce The High Quality Wheel Loader!
