• Model NO.：SE210-9
• Drive Type：Internal Combustion Drive
• Bucket Capacity：0.5~1.0m³
• Size：Medium-Sized
• Certification：CE, ISO9001: 2000
• Condition：New
• Transport Package：Roro
• Specification：20800kg
• Trademark：shantui
• Origin：China
• HS Code：8429521200
• Production Capacity：500,Month

Basic Info.

Model NO. SE210-9 Drive Type Internal Combustion Drive Bucket Capacity 0.5~1.0m³ Size Medium-Sized Certification CE, ISO9001: 2000 Condition New Transport Package Roro Specification 20800kg Trademark shantui Origin China HS Code 8429521200 Production Capacity 500/Month

Product Description

Good price China SE210-9 SHANTUI mediume-size crawler excavator weight 20.8 Tons with top engine

Product Description



High-end system configuration

B5.9 six-cylinder engine conforms to China-II emission regulation and features strong power and high durability. It's equipped with three-stage fuel filtration system to safeguard the working. The optimized negative-flow control hydraulic system features reliable performances and easy maintenances. The large displacement main pump perfectly matches with the engine to achieve higher machine speed.

Firm and durable structural parts

1. It's equipped with standard reinforced bucket.

2. The cast front support is attached with reinforcement panels at key portions to achieve higher reliability.

2. The cast casing is used for the boom front yoke and rear seat to carry multi-direction variable torque loads.

4. The undercarriage in X-shaped box structure ensures high carrying capacity and the thickened panels are applied at key portions to improve reliability and durability.

Comfortable and convenient operating environment

It's installed with standard radio with USB port, cigarette lighter, fire extinguisher, and escape hammer and is provided with multiple storage spaces. The functional buttons are centrally arranged to ease the operations and achieve high elegance. The cab features large space and broad vision and the control devices are reasonably arranged to realize convenient and comfortable operations. The seat features high comfort and fatigue-resistance. The  high-power automatic A/C system features strong airflow output and multi-directional air vents without dead angle.

Intelligent electronic control and optimal power control

The intelligent electronic control system perfectly matches with power system and hydraulic system to improve economy. The accelerator percentage control realizes the accurate match between engine output power and load demand.



Convenient maintenances

1. Supported by two cylinders, the backward-opening engine hood features handy opening, large opening angle, and easy maintenances.

2. The electric parts are centrally arranged to ease the checking and maintenances.

3. The filling of coolant and the replacement of air filter element are easily accessible and the assembled radiator mesh enclosure eases the cleaning.

4. The three-stage fuel filter element is installed to achieve one-stop replacement and easy maintenances.

The fuel filter element, engine oil filter element, and pilot filter element are centrally arranged so that all maintenances and replacements can be completed from on same position

5. The lubricating oil filler ports are centrally arranged to easy the routine maintenances.



Parameters:

Comparative item	SE210-9
Overall dimensions
Overall length (mm)	9625
Ground length (During transport) (mm)	4915
Overall height (To the top of boom) (mm)	3075
Overall width (mm)	2800
Overall height (To top of cab) (mm)	3055
Ground clearance of counterweight (mm)	1075
Minimum ground clearance (mm)	470
Tail turning radius (mm)	2925
Track length (mm)	4140
Track gauge (mm)	3360
Track width (mm)	2800
Standard track shoe width (mm)	600
Turntable width (mm)	2725
Distance from slewing center to tail (mm)	2920
Working range
Maximum digging height (mm)	10095
Maximum dumping height (mm)	7190
Maximum digging depth (mm)	6490
Maximum vertical digging depth (mm)	5915
Maximum digging distance (mm)	9860
Maximum digging distance at ground level (mm)	9675
Working device minimum turning radius (mm)	2970
Engine
Model	B5.9-C
Type	6-cylinder inline and water-cooled and turbocharged
Displacement (L)	5.9L
Rated power (kW/rpm)	112kW/1950rpm
Hydraulic system
Type of hydraulic pump	Variable displacement plunger pump
Rated working flow (L/min)	2x218L/min
Bucket
Bucket capacity (m³)	0.90m3 (SAE)
Swing system
Maximum swing speed (r/min)	11r/min
Brake type	Mechanically applied and pressure released
Digging force
Bucket arm digging force (KN)	99kN/107KN
Bucket digging force (KN)	135kN/146KN
Operating weight and ground pressure
Operating weight (kg)	20800kg
Ground pressure (kPa)	47.5KPa
Traveling system
Traveling motor	Axial variable displacement plunger motor
Traveling speed (km/h)	3.15/5.15km/h
Traction force (KN)	214kN
Gradeability	70% (35°)
Tank capacity
Fuel tank capacity (L)	330L
Cooling system (L)	28L
Engine oil capacity (L)	22L
Hydraulic oil tank/system capacity (L)	270/400L
