• Model NO.：SEM917
• Transport Package：Carton Package
• Trademark：Sinomada
• Origin：China
• HS Code：8429521200
• Production Capacity：100pieces,Month

ModelSEM917Operating Weight Standard13,500 kg / 13,820 kg (With ROPS)With Front & Rear Counterweight13,780 kg / 14,100 kg (With ROPS)With Front Blade14,130 kg / 14,450 kg (With ROPS)With Ripper+Front Blade14,410 kg / 14,730 kg (With ROPS)Operating Specifications Top Speed, Forward40 kphTop Speed, Reverse29 kphMin. Turning Radius7,300 mmArticulation Angle, Left /Right20 °Gradeability30 °Wheelbase5,830 mmTravel Speed, Forward5.3 / 8.2 / 13.3 / 20.3 / 29 / 40 kphTravel Speed, Reverse5.3 / 13.3 / 29 kphDrawbar Pull78 kNEngine Engine ManufacturerSDEC (ShangHai Diesel)Engine ModelSC7H170. 1G2BRated Power125 @ 2,200 kN @ RPMMax. Torque750 @ 1,400 Nm @ RPMEmissionTier 2Displacement6.5 LBore105 mmStroke124 mmNumber of Cylinders6Transmission TypeConverter, PowershiftPowershift Pressure1.3 ~ 1.7 MpaForward / Reverse Gears6 / 3Parking BrakeSpring Actuated, Air ReleasedTandem Axle ModelST18DifferentialNo-SpinService BrakeCaliper-DiscSecondaryDual CircuitOscillation Front Up15°Oscillation Front Down25°Front Axle Ground Clearance640 mmWheel Lean, Left / Right±18°Max. Oscillation±16°Steering Range, Left / Right±45°Hydraulic System Circuit TypeLoading Sensing, PPPCPump TypeVariable PistonMax. Pump Output162.8 L / minMax. System Pressure22 MPaStandby Pressure2.0~2.2 MPaMoldboard Blade Width, Standard3,669 (12')mm (Ft)Blade Width, Optional3,972 (13') mm (Ft)Moldboard Height610 mmMoldboard Thickness20 mmThroat Clearance112 mmFloat FunctionOptionalMoldboard Sideshift, LH647 mmMoldboard Sideshift, RH528 mmCircle Centershift, LH512 mmCircle Centershift, RH663 mmMax. Blade Position Angle90 °Blade Tip, Forward40 °Blade Tip, Backward5 °Blade Cutting Angle24-69 °Max. Shoulder Reach outside of Tires, LH1,748 mmMax. Shoulder Reach outside of Tires, RH1,912 mmMax. Lift above Ground460 mmMax. Cutting Depth725 mmService Refill Capacity Fuel Tank218 LEngine Oil17.5 LCoolant37 LTransmission17 LDifferential Case27 LTandem Case, Each Side50 LCircle Drive, Non Slip Clutch2 LCircle Drive, With Slip Clutch7 LHydraulic Oil Tank55 LMain Optional Equipments Mid Mounted Scarifier(MMS) / MMS ReadyCircle SaverFront Counterweight, 1000kgRear Counterweight, 600kgBlade FloatCold StartElec-Hydraulic Pin PullerHigh Profile ROPS CabHydraulic Blade TipCircle Drive with Slop ClutchFront Blade / Front Blade ReadyRear Ripper / Rear Ripper ReadyRear Fender
