• Model NO.：rack shelf roll forming machine
• Punching Die Material：Cr12
• Punching：Continually
• Certificate：Ce
• Quality Control：ISO9001
• Transport Package：40gp
• Specification：CE SGS BV ISO
• Trademark：Zhongyuan
• Origin：China
• HS Code：84552210
• Production Capacity：10sets,Month


Technical parameterItemSpecification
Raw MaterialTypeGalvanized steel sheetThickness(mm)2.0-3.0mmYield strength(mpa)550Roller materialCr12 mould steel being quenched treatment,with digital-controlled processionShaft for rollers Solid shaft with 82mm,processed with cylindrical grinderForming speed(m/min)About 15Speed adjusting modeMitsubishi frequency transformerRoller drive                                               Decelerating motor + Gear driveCutting modeHydraulic cuttingCutter material Cr12 mould steelLength measurementNemicon EncoderControl modeMitsubishi PLCOperating modeButton + Mitsubishi Touch screenMain motor power(kw)2*11KWTotal power(kw)30.5 KWProcess flowDecoiler -- Leveling sheet-- Punching holes--Forming---Hydraulic Cutting - product to run out table
Components of machineDecoiler (manual decoiler and hydraulic decoiler for option)1set  Leveling equipment1setPunching machine1setRoll forming equipment1setPost cutting equipment1setHydraulic station1setPlc control panel1setRun out table (auto. Stacker for option)1set
About Zhongyuan



Our customers
