• Model NO.：SWE25F
• Size：Small-Scale
• Certification：ISO9001
• Condition：New
• Hydraulic Cylinder Brand：Kyb
• Warranty：2 Years
• Rated Speed：2.9,Km,H
• Maximum Digging Height：3085mm
• After Warranty Service：Video Technical Support
• Color：Blue
• Unique Selling Point：High Digging Power
• Applicable Industries：Manufacturing Plant
• Maximum Digging Depth：1825mm
• Max Digging Radius：1221mm
• Hydraulic Valve Brand：Kyb
• Local Service Location：Indonesia
• Operating Weight：2ton
• Engine Brand：Isuzu
• Showroom Location：Indonesia
• Specification：Blue
• Trademark：SUNWARD
• Origin：Hunan, China
• Production Capacity：100000 Set,Sets Per Year

Type of cabCabin/CanopyBucket capacity,std.0.066m3Bucket width600mmMachine weight2640kg

Dimensions

Overall length4262mmOverall height2400mmOverall width1500mmGround clearance280mm

Engine

BrandYanmarModel3TNV80F-SPSUDisplacement1.267LOutput14.6kW/2400rpm

Working ranges



Max. cutting height4445mmMax. loading height3110mmMax. digging depth2705mmMax. vertical wall digging depth2745mmMax. digging reach4845mmoom swing angle(left/right)66°/54°Front swing radius2143mmTail swing radius1050mmMax. digging force(Arm)14kNMax. digging force(Bucket)24kNTrackTypeRubber track/Steel trackTrack width300mm

Undercarrige

Track length1990mmLength to center of rollers1560mmLenhth to center of track1200mmTravelling speed(High/Low)4.4/2.2 km/hGradeability30°Swing speed10rpmGround pressure25kPaDozer sizeWidth1500mmHeight325mmLifting capacity (Height/Depth)330/3.20 mmHydraulic pumps2 variable plunger pumps (2*28.8L/min)1 gear pump (19.2L/min)1 guide gear pump (6.5L/min)Swing motorPlunger motorTravel motor2-speed plunger motorFuel tank capacity42.5LHydraulic oil tank capacity30L
