Highway Hydraul Hammer Guardrail Pile Driver Equip
Ji Ning Hengwang Mining Machinery Co., Ltd.- Type：Vibratory Pile Hammer
- Pressure Pile Driver Type：Hydraulic Pile Driver
- Pile Hammer Type：Drop Hammer
- Power Source：Diesel
- Motor Power：55kw
- Noise：With Noise
Base Info
- Model NO.：HWH930
- Certification：ISO 9001:2000
- Condition：New
- Weight：5.2t
- Transport Package：Wooden Case
- Specification：3200*2000*2900mm
- Trademark：HW
- Origin：China
- HS Code：8430100000
- Production Capacity：3000pieces,Month
Description
Model
HWH930
Loader Type
930
Engine Power
55/60kw
Hydraulic system flow
220-280L/Min
Rated Pressure
15Mpa
Power Head
68#
Strike Frequency
400-800Bpm
Power Head Weight
140Kg
Drilling Speed
800-2000mm/min
Impactor Working Pressure
0.6-1.2Mpa
wheel-track
1470mm
Wheelbase
2000mm
Overall Dimension
4200*2300*2850mm
Weight
5.2T
Hammer flow
45-85L/min
Hammer Pressure
12-15Mpa
Drill Diameter
120-200mm
Impactor Impact frequency
900-1000Bpm
Air Consumption
7-13m³/min
