• Model NO.：XZ320D
• Certification：EPA, CS, CE, RoHS, ISO 9001:2000, ISO 9001:2008
• Condition：New
• Engine：Shangchai
• Transport Package：Nude
• Specification：CE
• Trademark：evangel
• Origin：Jiangsu, China
• HS Code：84306919
• Production Capacity：500 Sets,Month

Basic Info.

Model NO. XZ320D Certification EPA, CS, CE, RoHS, ISO 9001:2000, ISO 9001:2008 Condition New Engine Shangchai Transport Package Nude Specification CE Trademark evangel Origin Jiangsu, China HS Code 84306919 Production Capacity 500 Sets/Month

Product Description

Horizontal Directional Drill XZ280
1. Engine: Shangchai
2. Overall weight: 12500kg
3. DIMENSION (L* W* H): 7100* 2260* 2450mm
4. Top brand and good quality

Horizontal directional drilling machine  xz280
We are able to provide professional serive and high quality products.
Looking forward to sincere cooperation.


The horizontal directional drill is mainly used for laying and replacing various underground pipelines. The machine features advanced performance and high operation efficiency and comfortable working condition. The key components are purchased globally, and it is the ideal equipment for construction in industries of water supply, coal gas, electric power, telecommunication, heating and oil.


Model		XZ280
Engine		shangchai
Rated power	kW	140
Max.pullback/thrusting	kN	280/280
Spindle torque(max)	N.m	10000
Spindle speed	r/min	0-120
Backreaming diameter	mm	Ø750
Tubing length(single)	m	3
Tubing diameter	mm	Ø73
Entry angle	°	10-23
Mud flow rate(max)	L/min	250
Mud pressure (max)	bar	80
Overall weight	kg	12500
DIMENSION (LxWxH)	mm	7100×2260×2450

*********************************************************************************








********************************************************************************************
