19ton 179HP Liugong Compactor 6118e Vibratory Single Drum Road Roller
Maxizm Construction Machinery (Qingdao) Co., Ltd.- After-sales Service：Video Technical Support
- Warranty：1 Year Warranty
- Type：Road Roller
- Working Method：Vibration
- Axle：Biaxial Dual-Drum
- Grinding Wheel Type：Tire Grind
Base Info
- Model NO.：6118E
- Compaction Depth：40cm
- Engine Type：Diesel Engine
- Travel Speed：40cm,s
- Centrifugal Force：40KN
- Certification：EPA, CE, ISO 9001:2000, ISO 9001:2008
- Condition：New
- Operating Mass：19000 Kg
- Mass on Vibrating Drum：9500 Kg
- Mass on Drive Axle：9500 Kg
- Front Drum Static Linear Load：437 N,Cm
- Model：Shangchai
- Emission Regulation：Stage II
- Rated Power：132 Kw (179 HP) @ 1800 Rpm
- Vibration Frequenc：28 , 33 Hz
- Drum Diameter：1600 mm
- Min. Groundclearance：450 mm
- Wheelbase：3230 mm
- Transport Package：Nude, Roro, Container
- Specification：6450 mm*2340 mm*3150 mm
- Trademark：Liugong
- Origin：Guangxi, China
- HS Code：8429401100
- Production Capacity：1000 Units,Year
Description
Operating Mass
19000 kg
Mass On Vibrating Drum
9500 kg
Mass On Drive Axle
9500 kg
Front Drum Static Linear Load
437 N/cm
Model
Shangchai SC8D180.3G2B1
Emission Regulation
Stage II
Rated Power
132 kW (179 hp) @ 1800 rpm
Vibration Frequency
28 / 33 Hz
Nominal Amplitude
2.0 / 1.3 mm
Centrifugal Force
360/275 kN
Drum Diameter
1600 mm
1st Maximum Speed, fwd
2.7 km/h
2nd Maximum Speed, fwd
5.2 km/h
3rd Maximum Speed, fwd
11 km/h
Theoretical Gradeability
30%
Min. GroundClearance
450 mm
Wheelbase
3230 mm
Min. Outside Turning Radius
7000 mm
Overall Length
6450 mm
Overall Width
2340 mm
Overall Height
3150 mm
