3 Tons Lonking New Mini Self Front End Wheel Loader Truck Cdm833
Evangel Industrial (Shanghai) Co., Ltd.- After-sales Service：Provide
- Warranty：1 Year
- Certification：TUV, UL, ISO, RoHS, CE
- Condition：New
- Rated Load：3-6t
- Transmission：Hydraulic
Base Info
- Model NO.：CDM833
- Load and Unload Mode：Front Discharge
- Walking Mode：Wheeled
- Type：Small Loader
- Transport Package：Sea
- Origin：China
Description
Overview
Contact InformationNO. DESCRIPTION UNIT STD High Dump A Overall Height - Bucket Raised mm 4737 5080 B Bucket Pin Height at Max. Lift mm 3710 4064 C Dump Clearance at Max. Lift ( 45°) mm 2904 3249 D Reach at Max. Lift and 45° Dump mm 1095 1002 E Rack Back Angle at Carry ° 46.3 46.6 F Rack Back Angle at Ground ° 40 40.9 G Digging Depth mm 30-40 30-40 H Rack Back Angle at Max. Lift ° 50.7 47 I Dump Angle at Max. Lift ° 46.6 45 J Carry Height mm 400 400 K Ground Clearance mm 345 345 L Center Line of Front Axle to Hitch mm 1425 1425 M Wheel Base mm 2850 2850 N Overall Length mm 7200 7450 O Departure Angle ° 27 27 P Height to Top of Cab mm 3180 3180 Q Overall Width over Bucket mm 2500 2500 R Min. Turning Radius over Bucket mm 6190 6280 S Min. Turning Radius over Tires mm 5675 5675 T Steering Angle - Left/Right ° 35 35 U Width at Tread Center mm 1850 1850 V Overall Width over Tires mm 2320 2320 OVERALL DATA Bucket Capacity 1.7m³ 1.7m³ Rated Payload 3000kg 3000kg Operating Weight 10300±300kg 10500±300kg Traction Force 97±3kN 97±3kN Breakout Force 105±3kN 95±3kN L×W×H(mm) 7200×2500×3180 7450×2500×3180 ENGINE&ELECTRICAL SYSTEM Maker/Model WEICHAI/WP6G125E22 Emission Standard EPA (Tier2)/National2 Engine Type 4 Stroke,Turbocharged,Water-cooled,Direct Injection,Diesel Engine Rated Power 92kW(125hp)/2200rpm Maximum Torque 500N·m/1400-1600rpm Bore x Stroke (mm) 105×130 No. of Cylinders/Displacement 6/6.75L Compression Ratio 18 Air Cleaner Three Stage Air Cleaner Alternator 55Amp Battery 2-24V/105Ah Starting Motor 24V/6kW Heating Capacity (W) 5000W Cooling Capacity (W) 4700W DRIVE TRAIN Transmission Type Countershaft Powershift Transmission Shift Type Mechanical Powershift Control Pressure of Transmission 1.1-1.5MPa Torque Converter Type Single-stage,Single-turbine,3-element Torque Ratio 3.2 Axles Rigid Front Axle&Oscillating Rear Axle Rear Axle Oscillation (°) ±10° Differential Conventional Main Reducer Spiral Bevel,1-stage Reduction Final Reducer Planetary Reduction Tire 17.5-25 L-3 12PR TT Travel Speeds km/h 1st 2nd 3rd 4th Forward 7 12 24 36 Reverse 8.5 28 BRAKE SYSTEM Service Brake Single Circuit Caliper,Dry Brake Setting Pressure 0.70-0.78MPa Parking Brake Flexible Shaft Controlled Caliper Brake Emergency Brake Flexible Shaft Controlled Caliper Brake STEERING SYSTEM Type Hydraulic Load Sensing System Pump Gear Pump,176L/min·2200rpm System Pressure 14MPa Cylinder Type Double Acting Bore x Stroke 2-80×315mm Steering Angle ±35° HYDRAULIC SYSTEM Type Mechanical Shift Control Pump Gear Pump,176L/min·2200rpm Control Valve 2 Spool (Bucket&Boom) System Pressure 16MPa Cylinder Lift Cylinder 2-125×784mm No.-Bore x stroke Tilt Cylinder 1-140×553mm Joystick Control Pressure --MPa Cycle Time Raise Dump Lower Total (Sec) 5.5 1.3 3.7 10.5 SERVICE REFILL CAPACITY Fuel Tank (L) 200L Hydraulic Tank (L) 150/155(3rd Spool for Auxiliary Function)L Crankshaft (L) 17L Transmission (L) 36L Front Axle/Rear Axle (L) 18.5L/18.5L
