2500 Kg FL936h New Telescopic Loader 3 Ton Front End Loader with Enlarged Bucket

Sinomada Heavy Industry (Changsha) Co., Ltd.
  • After-sales Service：Available
  • Warranty：2 Years
  • Certification：ISO, CE
  • Condition：New
  • Rated Load：3-6t
  • Transmission：Power

Base Info

  • Model NO.：FL936H
  • Load and Unload Mode：Front Discharge
  • Walking Mode：Wheeled
  • Type：Small Loader
  • Transport Package：Nude Package
  • Specification：7170*2420*3200mm
  • Trademark：shantui
  • Origin：China
  • HS Code：8429510000
  • Production Capacity：100untis,Month

Description

Operating mass(kg)10250Bucket capacity (m3)2Rated load(kg)3000Traction(kN)101Digging force(kN)98Gradeability30Unloading height(mm)2935Unloading distance(mm)1100Min. ground diatance(mm)340Wheel tread(mm)1850Wheelbase(mm)2880Bucket outer turning radius(mm)5990Outline distance(mm)7170*2420*3200EngineModelWeichai WP6G125E22Max. torque(N·m)500Rated power(kW)92Rated rotational speed(rpm)2200Gearbox shiftFront:4 gears Rear:2 gearsMax. speed39Type17.5-25Ply rating12Steering angle38Operating modelMechanically controlSum of three items(s)9.2Fuel tank(L)170Hydraulic oil tank(L)120
