• Model NO.：ZE215E
• Size：Medium-Sized
• Certification：CE, ISO9001: 2000
• Condition：New
• Operating Mass：21300kg
• Swing Speed：11.5r,Min
• Maximum Drawbar Pull：192kn
• Bucket Digging Force(ISO)：157kn
• Arm Digging Force(ISO)：110kn
• Travel Speed (High / Low)：3.3,5.5km,H
• Engine Manufacturer：Cummins
• Rated Power：112,1950kw,Rpm
• Max. Digging Depth：6610mm
• Max. Digging Height：9615mm
• Transport Package：Container,RO-RO
• Specification：8090* 2580* 2900 mm
• Trademark：ZOOMLION
• Origin：China
• HS Code：8429521200
• Production Capacity：100,Month

ItemUnitZE215EKey    ParameterWorking masskg21800Rated powerkw/rpm112/1950Standard bucket capacity(SAE)m31.0System    flow
   (Max. pressure/ Max. flow)-

34.3/37.3 Mpa

2×206 L/min

Engine model-Cumins B5.9-C(150hp)Max. torqueN.m/rpm614/1500Traveling speed (low/high)km/h3.3/5.5Slewing speedrpm11.5Gradeability°°35°Max.  drawbar pullkN192Digging force of bucket (ISO)kN157Digging force of stick (ISO)kN110Basic    ParameterSlewing radius of tailmm2840Tail lengthmm2800Counterweight ground clearancemm1050Min. ground clearancemm440Ground contact lengthmm3380Track lengthmm4180Track gaugemm2200Track widthmm2800Track shoe widthmm600Height of cab(mm)mm2990Slewing table widthmm2720Operating    RangeMax. excavating radiusmm9830Max. excavating distancemm9650Max. excavating heightmm9615Max. discharging heightmm6785Max. excavating depthmm6610Max. vertical excavating depthmm5760Min. slewing radius of frontmm3290
