New Earthmoving Mahinery Shantui 240HP Dh24 Bulldozers for Sale
Maxizm Construction Machinery (Qingdao) Co., Ltd.- After-sales Service：Support
- Warranty：1 Year
- Type：Universal Type
- Transmission：Power Transmission
- Walking Mode：Crawler
- Load and Unload Method：Front Discharge
Base Info
- Engine Power：147~515kw
- Certification：CE, ISO9001: 2000
- Condition：New
- Color：Yellow
- Operating Weight (Kg)：23850
- Ground Pressure (Kpa)：68.4
- Rated Power/Rated Speed (Kw/Rpm)：185,1900
- Overall Dimensions of Machine (mm)：6095*3640*3192
- Forward Speed (Km/H)：0-11km,H
- Reversing Speed (Km/H)：0-11km,H
- Center Distance of Track (mm)：3050
- Width of Track Shoes (mm)：560
- Ground Length mm：3075
- Digging Depth (mm)：540
- Transport Package：Null
- Specification：6095*3640*3192mm
- Trademark：SHANTUI
- Origin：Shandong, China
- HS Code：8429111000
- Production Capacity：1000,Momth
Description
Overview
Product Description
Detailed Photos
| Parameter name | DH24-B2 XL | DH24-B2 LGP |
| Performance parameters | ||
| Operating weight (Kg) | 23850 | 26450 |
| Ground pressure (kPa) | 68.4 | 40.9 |
| Engine | ||
| Engine model | Weichai WD12G250E202 | Weichai WD12G250E202 |
| Rated power/rated speed (kW/rpm) | 185/1900 | 185/1900 |
| Overall dimensions | ||
| Overall dimensions of machine (mm) | 6095*3640*3192 | 6255*4365*3228 |
| Driving performance | ||
| Forward speed (km/h) | 0-11 | 0-11 |
| Reversing speed (km/h) | 0-11 | 0-11 |
| Chassis System | ||
| Center distance of track (mm) | ||
| Width of track shoes (mm) | 560/610(Optional)/660(Optional) | 910 |
| Ground length(mm) | 3050 | 3482 |
| Tank capacity | ||
| Fuel tank (L) | 390 | 390 |
| Working device | ||
| Blade type | Semi-U | Straight-tilt |
| Digging depth (mm) | 540 | 550 |
| Ripper type | 3 shank | - |
| Ripping depth (mm) | 655 | - |
